 Page54        

 SlimPhattyUser’sManualTheUserInterface        
 Page55

 SlimPhattyUser’sManualTheUserInterface
SECTION
CONTROL/PARAMETER FUNCTION CC VALUE/RANGE
Interface Panel
MASTER Master mode switch - -
PRESET Preset mode switch - -
CURSOR Navigation control - -
ENTER Data entry control - -
GLIDE ON/OFF Turns Glide ON/OFF 65 0 (OFF), 64 (ON)
OCTAVE UP Octave increment switch - -
OCTAVE DOWN Octave decrement switch - -
Modulation
LFO RATE Adjusts the LFO frequency 3 0 – 127
AMOUNT Adjusts the modulation amount 6 0 – 127
SOURCE Selects the modulation source 68 0 (TRI), 16 (SQUARE)
32 (SAW), 48 (RAMP)
64 (FILT ENV), 80 (OSC2)
DESTINATION Selects the modulation destination 69 0 (PITCH), 16 (FILT)
32 (WAVE), 48 (OSC2)
LFO SYNC SOURCE Selects the LFO synchronization source 102 0 (INT), 64 (MIDI CLK)
LFO SYNC CLOCK DIV Sets the LFO synchronization clock divider 103 See table for list of values
MOD SOURCE 5 Selects the Mod 5 Source 104 0 (FILT), 64 (S&H)
MOD SOURCE 6 Selects the Mod 6 Source 105 0 (OSC2), 64 (NOISE)
MOD DEST 2 Selects the second mod destination 106 0 (OFF), 25 (PITCH)
50 (FILT), 75 (WAVE)
100 (OSC2)
Oscillators
OSC 1 OCTAVE Sets the octave of oscillator 1 74 16 (16’), 32 (8’)
48 (4’), 64 (2’)
WAVE Sets the waveform of oscillator 1 9 0 – 127
OSC 1 LEVEL Adjusts the volume level of oscillator 1 15 0 – 127
GLIDE RATE Sets the portamento rate time 5 0 – 127
1-2 SYNC Turns oscillator sync ON/OFF 77 0 (OFF), 64 (ON)
OCTAVE Sets the octave of oscillator 2 75 16 (16’), 32 (8’)
48 (4’), 64 (2’)
OSC 2 FREQ Adjusts the frequency of oscillator 2 10 0 – 127
WAVE Sets the waveform of oscillator 2 11 0 – 127
OSC 2 LEVEL Adjusts the volume level of oscillator 2 16 0 – 127
PITCH BEND UP AMT Selects the pitch end UP amount 107 0 – 127
PITCH BEND DN AMT Selects the pitch bend DOWN amount 108 0 – 127
Filter
CUTOFF
(SEE NOTE 1)
Adjusts the filter cutoff frequency
19 (MSB)
51 (LSB)
0 – 127
RESONANCE Adjusts the filter resonance parameter 21 0 – 127
KB AMOUNT Adjusts the amount of pitch CV affecting the cutoff 22 0 – 127
EG AMOUNT Adjusts the EG amount affecting the cutoff 27 0 – 127
OVERLOAD Adjusts the amount of filter overdrive 18 0 – 127
FILTER POLES Selects the number of filter poles 109 0 (1), 32 (2), 64 (3), 96 (4)
FILTER VELOCITY SENS Sets the amount of filter velocity sensitivity 110 See table for list of values
Slim Phatty MIDI CC messages
