other side has reached the minimum (rear ballasts only), there will be a pop-up that
prompts the user to adjust weight in the boat to achieve the desired roll values. The pitch
value will have a similar pop-up but will only occur once the roll is finished moving (either
achieved or maxed out). When the roll or pitch cannot move, the color of the set points will
turn red.
AutoWake Achieved: This will occur:
• Once the current pitch and roll values (average value over 5 seconds) are within
0.25 degrees
• AutoWake becomes Active.
The colors of the set points will be green. The achieved status will remain until the pitch or
roll is outside of 0.75 degrees of the set point (in which case it will go back to the AutoWake
Active state).
Static AutoWake Active: This state will occur when:
• AutoWake is turned on
• Actual speed is less than 3mph
• Boat is turned on.
