Mooney M20V - Page 63

MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Page
Date
6
MAR 2017
Rev Date
TURBOCHARGER
Turbocharger Mfg. CMI/KELLY AEROSPACE
Type Exhaust Driven
Model TA36
PROPELLER
Propeller Mfg. Hartzell 3- Blade
Type Constant Speed
Model PHC- J3YF- 1RF/F7693DF- 2
Model PHC- J3YF- 1RF/F7693DF(B)- 2
Note: (B) Indicates W/Boots Installed)
Pitch Angle @ 30 in. Sta. LOW 16.5
o
(+/- ) 0.2
o
HIGH 38.0
o
(+/- ) 1.0
o
Diameter - Min/Max 75/76” 190.5/193.0 cm
PROPELLER - OPTIONAL
Propeller Mfg. Hartzell 3- Blade
Type Constant Speed
Model PHC- J3YF- 1RF/F7498
Model PHC- J3YF- 1RF/F7498(B)
Note: (B) Indicates W/Boots Installed)
Pitch Angle @ 30 in. Sta. LOW 17.0
o
(+/- ) 0.2
o
HIGH 38.0
o
(+/- ) 1.0
o
Diameter - Min/Max 74/76” 188.0/193.0 cm
Governor Hartzell
Governor Hartzell
AIRFRAME
- WEIGHTS & LOADINGS
Approximate Empty Weight 2319 Lbs. 1051.9 Kg.
Gross Weight 3368 Lbs. 1528.0 Kg.
Useful Load - No Options 1049 Lbs. 475.8 Kg.
Wing Loading 19.26 Lbs./Sq.Ft. 94.0 Kg./Sq.m
Power Loading 12.03 Lbs./Hp 5.46 Kg/Hp
WINGS
Airfoil At Wing Root 63
2
215
Airfoil At Wing Tip 64
1
412
Mean Aerodynamic Chord At Wing
Sta.94.85
61” 241 cm
Center- of- Gravity Range 41.0 to 51.0
Geometric Twist (DEG) 1.5 Degrees
Incidence Angle (DEG) From Sta 20.
to Wing Tip
2.5 Degrees
Dihedral Angle (DEG) 5.5 Degrees
Aspect Ratio 7.448
Tap er R a tio (C S /C T ) 2.271
6-00-01
