Mooney M20V - Page 64

MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Page
Date
7
MAR 2017
Rev Date
FUSELAGE
- CABIN DIMENSIONS
Height 44.5” 113 cm
Width 43.5” 110.5 cm
Length 126” 315 cm
Cabin Door Width 34.0” 86.36 cm
Cabin Door Height 32.5” 82.55 cm
- BAGGAGE COMPARTMENT
MAX. Loading 120 Lbs. 54.4 kg
Baggage Space 22.6 Cu. Ft. 0.678 Cu. M.
Baggage Door Width 17” 43.2 cm
Baggage Door Height 20.5” 52.1 cm
Hat Rack Capacity 10 Lbs. 4.5 Kg
- LANDING GEAR
Type Tricycle, Retractable
Operation Electrical
Wheel Track 9’ 2” 279.4 cm
Wheel Base 6’ 7- 1/2” 201.9 cm
Tire Size - Nose (6- Ply Rating) 5.00x5
Tire Size - Main (6- Ply Rating) 6.00x6
Tire Pressure - Nose 49 Lbs./Sq. In.
Tire Pressure - Main 42 Lbs./Sq. In.
6-00-02 - AIRCRAFT DIMENSIONS
SUBJECT
STANDARD METRIC/OPT/MISC
- DIMENSIONS
Wing Span 36’ 6” 1112.5 cm
Fuselage Length 26’ 8” 812.8 cm
Tail Height 8’ 6” 259.1 cm
Stabilizer Span 11’ 9” 358.1 cm
-AREAS
Wing 174.8 Sq. Ft. 16.2 Sq. meters
Ailerons 11.4 Sq. Ft. 1.1 Sq. meters
Flaps 17.9 Sq. Ft. 1.7 Sq. meters
Vertical Fin 7.8 Sq. Ft. 0.7 Sq. meters
Rudder 6.3 Sq. Ft. 0.5 Sq. meters
Horizontal Stabilizer 21.4 Sq. Ft. 1.9 Sq. meters
Elevators 13.0 Sq. Ft. 1.2 Sq. meters
6-00-02
