6-00-03 - AIRCRAFT STATIONS
NOTE
The datum line station 0.0 is 13 inches aft of the nose gear trunnion pivot point (Reference Figure 8- 2.).
(1112.5 cm)
(279.4 cm)
76”
(193.04 cm)
(201.9 cm)
6’- 7 1/2”
9’- 2”
(358.1 cm)
11’ - 9”
(259.1 cm)
8’- 6”
36’- 6”
(812.8 cm)
26’- 8”
PRINCIPAL AIRCRAFT DIMENSIONS
FIGURE 6- 1
