K6862043
3/11/14
11
49. Remove fastener (1) from the storage cubby on the
right side of the center dash trim panel. Carefully
disengage all retainer clips and pry off the trim panel (2).
47. Remove the edge trim (1) from the center console
cover panel.
48. Remove fasteners (1) at the front edge of the center
console cover panel (2). Remove the cover panel.
1
www.mopar.com
2
1
2
1
