mopio Haylee - Step 11: Shelf Pin and Shelf Placement; Step 12: Door Roller and Stopper Installation

TV
STAND, 59" | 11
Step 12
Q
x4
C
x4
E
x8
P
x4
H
x2
11
Q
P
H
8
C
E
P
8
H
C
E
Plug in shelf pin Q into the
desired hole positions and
place the shelves gently on
top of the shelf pin.
Please check the illustration
and identify the correct
position of pin sliding.
Prepare Door No.8 (2pcs).
Install sliding roller C with
screw E. Insert the pin P onto
side hole as indicated on the
illustration.
Please check carefully the
correct orientation for
stopper H.
Step 11
