mopio Haylee - Assembly Steps; Step 1: Initial Board Assembly; Step 2: Connecting Main Boards

TV
STAND, 59" | 06
Step 1
Step 2
D
x16
A
x8
O
x8
B
x8
1
A
3
D
D
4
10
D
D
9
1
3
4
9
10
B
O
Ensure your floor is
properly protected, then
take out board No. 1, No.3,
No. 4, No. 9, No. 10. Screw
cambolt A to board No. 1
(don't over screw). Plug in
dowel D into side holes of
board No.3, No. 4, No. 9,
No. 10.
Please ensure you screw or
plug into the correct hole
according to the illustration.
Install board No.3, No. 4,
No.9, No.10 onto board No1.
By inserting camlock B and
tightening it with Allen key
provided or screwdriver.
Plug in cover cap O to hide
the screw.
Please ensure the correct
orientation for board No.3,
No. 4, No. 9, No. 10 and the
camlock placement
orientation. Refer to the
illustration carefully.
Please check carefully this
illustration, the front side
should be showing the groove.
