mopio Haylee - Step 7: Dowel Insertion on Leg Frame; Step 8: Attaching Leg Frame to Body

TV
STAND, 59" | 09
Step 7
Step 8
D
x6
F K
x10
D
2
K
F
Plug in dowel D into the
holes on the leg frame.
Please refer to the
illustration carefully for the
dowel hole positions .
You may require extra pair of
hands to complete this step.
Position leg frame upside
down and install it to the
table body board No.2.
Insert screw K into the
brackets found on leg frame
and tighten the screw with
Allen key to secure the leg.
