Morco G11E - GAS CONSUMPTION; BURNER PRESSURE; BURNT GAS FLOW AND SMOKE TEMPERATURES; AIR FLOW NECESSARY FOR THE COMBUSTION

• GAS CONSUMPTION
GAS PRESSURE AT
TIPE OF GAS GAS FLOWAT 15ºC and 760 mm Hg APPLIANCE INLET
(Standarised gases) (mbar)
G11E D61B-D61E
Butane 1,8 kg/h. 0,88 kg/h. 28-30
Propane 1,8 kg/h. 0,88 kg/h. 37
Natural 2,3 m
3
/h. 1,2 m
3
/h. 20-25
PIPE WORK CONNECTION SIZES
GAS Butane/Propane-Natural 10 or 15 mm.
WATER Inlet (cold) 15 mm.
Outlet (hot) 15 mm.
Flueway D61B and D61E ø 90 mm.
G11E ø 110 mm.
• PIPE WORK DIAMETERS AND CONNECTION SIZES
• BURNER PRESSURE
9
TIPE OF GAS
(Standarised gases)
G11E D61B-D61E
Butane 27,5 mbar 29 mbar
Propane 36,3 mbar 36,9 mbar
Natural gas 16,4 mbar 19,4 mbar
• BURNT GAS FLOW AND SMOKE TEMPERATURES
MODELS G11E D61B-D61E
Flow g/s 13 7,8
Temperature 160ºC 137ºC
• AIR FLOW NECESSARY FOR THE COMBUSTION
TIPE OF GAS
(Standarised gases)
G11E D61B-D61E
Butane (1Kg.) 20,31 m
3
/h. 10,75 m
3
/h.
Propane (1Kg.) 20,63 m
3
/h. 10,92 m
3
/h.
Natural gas (1 m
3
) 23,27 m
3
/h. 12,14 m
3
/h.
