Morgana DocuFold Mk2 - Setting Perforators and Scorers

Page15
FOLDER
DocuFoldMk2
SETTINGPERFORATORS
Upperandlowerhubscanbepositionedontheshaftbyunscrewingthe2mm-grubscrew.
Slidethehubwiththebladeattachedalong,theshaftintopositiontocorrespondtothe
workusingthescaleasaguide.Forexample,toperforate20mmfromtheedgeofanA4
sheet,youwouldsetthebladeat190mm(210minus20).Whenpositionedre-tightenthe
2mm-grubscrew. Important - DoNotOverTightenThisGrubScrew
Slidethehubwiththeanvil,uptotheperforatorbladeandtheremainingupperandlower
hubs,setasthedrawing,rememberingtospreadthemtosupportthesheetfullyacrossits
width.
Cliptheperforatorstripperadjacenttotheupperhubasshown.Plugtheunitinto
position,fitthesheetsmootherintopositiontoholdthesheetsdownandrunthemachine
attheslowspeedtocheckposition.
Adjustthebackstopandsideguidetosuitthework.
Forworklongerthanthebackstopwillallow,removethebackstopandusetheextended
backstopthatislocatedunderneaththe catchtray.
Thereisafullrangeofperforatorbladesavailableasfollows:
Forfineperforation 56tooth - PartNumber1.99-41
ForPaper 28tooth - PartNumber1.99-12
ForheavierStock 20tooth - PartNumber1.99-10
Forusewith blades Anvil - PartNumber1.99-35
Slittersetforcutting - PartNumber1.99-13
SCORING
Itispossibletoscoreworkusingthepluginperforator.Thescorersaresplitintwo
halves,fittedtotheuppershaftandsetasshown inthedrawingusingthescaleonthe
unitasaguidetoposition.Thelowerhubsaremoveduptobutjustclearofthescoring
blade.Theactualgapiscriticalandmayrequiresomeexperimentationtoobtaina
satisfactoryscoreline.Aswithperforating,theremaininghubsmustbespreadtosupport
thesheetfullyacrossitswidth.
Scorersavailable:
TypeA PartNumber 6.99-05formostcard
TypeB PartNumber 6.99-06fordeepscore
TypeD PartNumber 6.99-09forpaper
