PAPER
NOTE.....
Theitemslistedaboverepresentpartswhicharesubjecttowear,loss,or
accidentaldamage,andisincludedforyourguidanceonly.
SectionandItemnumbersrefertotheillustrationsandtablesinthismanual.
Replacementofmostofthepartsfittedtoyourmachinerequiresspecialist
knowledgeandshouldthereforebeentrustedtoyourdealer.
PARTNo. DESCRIPTION
91 - 044 DRIVEBELT - Main
606 - 028 FOOT - Black
92 - 010 TRANSPORTBELT - Delivery
92 - 027-01 DRIVEBELT - Delivery-Flat12mm
607 - 022 TWINGRIPTIMINGBELT
93 - 021 FEEDBELT
93 - 022 DRIVEBELT - VacuumRoller
607 - 027 TIMINGBELT
93 - 028 SMOOTHER - Delivery
609 - 011 'O'RING
609 - 014 'O'RING
94 - 028 LOCKPINASSEMBLY - SideLay
95 - 017 HOSE - Vacuum
95 - 018 HOSE - SeparationAir
95 - 031 HOSE - Evacuation
95 - 032 HOSE - Exhaust
95 - 096 PCBDOCUFOLDCONTROL - LONGPLATE(EEC)
613 - 137 PLUNGER&SPRINGASSY
613 - 255 SOLENOIDCOIL
613 - 365 EMERGENCYSTOPSWITCH
613 - 376 SWITCH10AMP - 12vCOIL - (EEC)
95 - 049 ROTARYENCODERASSEMBLY
95 - 020 LENS - Display
609 - 013 'O'RING
95 - 046 SWITCHASSEMBLY - Reset/Pulse/Stream
95 - 062 SWITCHASSEMBLY - Feed
613 - 386 NUTCOVER
613 - 237 CAP
613 - 385 KNOB
96 - 028 - 02 FOLDROLLERASSEMBLY - Standard
96 - 049 - 02 FOLDROLLERASSEMBLY - Bottom
96 - 031 DRIVEBELT - LargeRollerDrive
601 - 021 MAGNETICACTUATOR
606 - 030 SCALLOPKNOB - Black
609 - 023 O'RING
97 - 101 PCB - FoldPlateMotorDrive
607 - 026 TIMINGBELT
607 - 025 TIMINGBELT
97 - 121 POT&LEADASSEMBLY
97 - 076 STEPPERMOTOR&LEADASSEMBLY
95 - 097 PCBDOCUFOLDCONTROL - IMPERIAL(USA)
613 - 383 SWITCH16 AMP - 12vCOIL - (USA)
RECOMMENDEDSPARES
