PAPER
SENSORCLEANING
Thesensorstodetectandcountthesheetsarelocatedontheendoftheballholderjust
nexttothefoldrollerunit.Ifthecounterisfailing,thesensorscanbeaccessedfor
cleaningbyremovingtherollerassemblyasdescribedabove
.Cleanbyusingasoft
brushordampcloth.
FOLDPLATES
- MAINTENANCE
Thefoldplatescanbeopenedupformaintenance,cleaning,etcbyremovingthelock
knob(H)andremovingthetwobolts(Z).Thefoldplatewillthenopenuptoenable
paperjamstoberemovedorcleaning.
