Morgana DocuFold Mk2 - Manual Fold Plate and Roller Adjustments

Page8
PAPER
Manual&FineAdjustment
Thefoldplatelengthcanbeadjustedmanually.Youmayneedtomakethisadjustmentto
achievetheexactcorrectlengthoffold.Button(CC)willselecttheupperfoldplate&button
(DD)thelowerfoldplate.Tomakeamanualadjustmenttothepositionoftheupperfoldplate,
pressandholdtheupperfoldplatebutton(CC).Thedimensionoftheupperfoldplatewillnow
bedisplayedinthecontrolpanel.
Note: - Theupperfoldplateshowsthedimensionofthefrontedgeofthe papertothefirstfold,
thelowerfoldplateshowsthedimensionfromthefirstfoldtothesecondfold.
Byturningtheselectknob(V)whilststillpressingandholdingtheupperfoldplatebutton(CC)
thefoldlengthoftheupperplatecanbelengthenedorshortened.Turningtheselectknob(V)
clockwisewilllengthenthefoldplatelengthandbyturninganti-clockwiseitwillshortenthe
foldplatelength.
Thedigitsbeforethedecimalpointshowninthedisplayareinmillimetres,each‘click’ofthe
selectknob(V)representsincrementsof0.1ofamillimetre.
Toadjustthepositionofthelowerfoldplate,press&holdthelowerfoldplatebutton(DD)and
adjustthelengthasdescribedabove.
Whenyouhaveadjustedthefoldlengthdimension,moveswitch(W)uptotheRunposition.
Theplateswillthenpositionthemselvesaccordingtothefoldlengthsyouhaveselected.
Withswitch(W)intheRunpositionthelefthandsideofthecontrolpanelwilldisplaytheletter
‘U’whichindicatesausersettingfollowedbyaletterthatindicatedthefoldtype.Forexample
theletters‘UL’wouldindicateaUsersettingbasedonaLetterfoldandtheletters‘UH’would
indicateaUsersettingbasedonaHalffold.
Tocheckthefoldpositionaftermakingamanualorfineadjustment,pressthesystemswitch
(T)andthenpressthefeedswitch(U)down.Themachinewillfeed3checksheetsandstop.
Aftercheckingthe3-rdsheet,ifthefoldpositioniscorrect,movethefeedswitchuptotheoff
positionandthen immediatelydowntothepulsepositionandthemachinewillstarttooperate.
Ifaftercheckingandfurtherplatepositioningisrequired,repeattheaboveprocedure.
Thefinalfoldplateanddeliverystackersettingscanbe‘stored’forretrievalatalaterdate,see
‘ToStoreAProgramme’.
