QUICK START GUIDE:
1. Set the paper gate gap (knob B) to two thickness of the paper to be folded.
2. Place the paper to be folded onto the loading table against the fixed side lay.
3. Unclamp the moving side lay (knobs A) and slide up against the side of the paper but allow
approximately a 1/2 mm or 1/64 inch gap between the moving side lay and the paper.
4. Clamp the backstop (F) onto the moving side lay at the back of the paper stack.
(Note) Do not attempt to load too many sheets onto the loading table during set up as this
may affect the feeding operation.
5. Look at the diagram showing the various fold types and standard paper sizes. Select the
type of fold that you require to make.
6. Unlock the fold plate locking knob (H) on the fold plates and press button L on the 1
fold plate. This will display the fold plate setting position. Turn the dial J to the dimension
required as indicated on the fold type diagram. Lock knob H. Repeat this operation for the
2 fold plate.
.
7. Fold a sheet of paper by hand to the finished folded size and set the delivery stacking roller.
8. Set the Speed Dial (R) to the required position.
9. Make sure you have power to the machine and that knob (S) is turned onto the ON position.
Start the machine with switch (T) and by pressing the feed switch on and off quickly you
will feed a single sheet. Check the fold for correct length and adjust if necessary. If correct,
zero the counter by pressing switch W upwards. Select batch size if required by turning
knob (V). Press the feed switch and the machine will start the folding operation.
