SENSOR CLEANING
FOLD PLATES - MAINTENANCE
The sensors, that detect and count the sheets, are located on the end of the ball holder
just next to the fold roller unit. If the counter is failing, the sensors can be accessed for
cleaning by removing the roller assembly as described above. Clean by using a soft
brush or damp cloth.
The fold plates can be opened up for maintenance, cleaning, etc by removing the lock
knob (H) and removing the two bolts (Z). The fold plate will then open up to enable
paper jams to be removed or cleaning on digital fold plates, replacement of the battery.
(Battery Part Number 613.379)
Page 22
