SETTING UP YOUR STEAM CLEANER
Filling the boiler
Unscrew the filler cap (1) anti clockwise
Fill the boiler with a maximum of 1.8
litres of water by using the funnel (15)
provided (Fig A)
Do not use any detergents
Screw the filler cap (1) clockwise until
finger tight. Do not over tighten.
Attaching Hose and Accessories
Pull down flap on the front of the
machine socket (4).
Insert the plug on the end of the hose (7)
into the machine socket (4) with button
side facing up, and push firmly until it
clicks into place. (Fig B)
Attach the desired accessory, i.e. large
floor brush (16), jet nozzle (18), to the
extension tube (9) or directly to the
handle (8), depending on the application.
The accessories vary per machine
The round brushes (19 & 20) can be
attached to the jet nozzle.
To join the extension tubes together, slide
one tube into the other until it locks into
place. (Fig C)
Attach the two tubes to the handle of
the hose. Slide the handle into the
extension tube until it locks into place.
(Fig D)
Some tasks may be easier with only one tube
fitted or none at all.
To connect the desired accessory directly
to the steam handle, slide the handle into
the accessory head until it locks into place.
When using the large floor brush (16) (or
the triangular brush (23), the brush
connector (17) needs to be fitted to the
brush first, in order to attach the same to
the extension tube.
To fit the connector:
1. Push the connector end, holding it upside
down, fully into the brush inlet. (Fig E)
A
C
D
E
B
4
