2. With one hand, lift the bottom baffle plate. With the other
hand, lift the brick panel up a few centimetres. This is best
done with a slotted screwdriver or similar. Once the brick
has been lifted, tip the diaphragm back into place, so the
brick panel is now released and can be lifted out.
3. Once the first brick panel has been removed from the sto-
ve, the diaphragm can be lifted and removed.
4. Lift the bottom baffle plate again and tip the other brick
panel out.
5. Lift the bottom baffle plate free of the tertiary combustion
air box and remove it.
