Table of Contents
Specifications i
W A R N I N G N O T I C E S
Installation Warning 4
Deburring Notice 5
Assembly Cautions 5-7
P A R T S L I S T
Replacement Parts 7
Tubing & Assemblies 8
Hardware 8
A S S E M B L Y
Assembly of Driven Elements 9-11
Assembly of Reflector Element 11-12
Boom 13
A T T A C H I N G C O A X
Preparing Coax 13-14
Phasing Line 14-15
Using an RF Choke 15
F I N A L C H E C K
15
S U G G E S T I O N S
Checking Antenna Before Final
Installation 18
Watch Out for Artificial Ground 18-19
Use of a Balun or Not 19
Stacking 19
P R O D U C T S U P P O R T
Technical Support 19
Warranty 20
Receipt of Shipment 20
