For Warranty Service Call: 833-474-0367 Range Owner’s Manual 20201109

GAS RANGE MANUAL

GAS RANGES WITH GRIDDLES

Models:

MR4-C-S

MR6-G24-C-S

MR6-C-S

MR10-G24-C-S

MR10-C-S

MR10-RGB24-C-S

MR4

MR6-G24

MR6

MR10-G24

MR10

MR10-RGB24

MR4-C

MR6-G24-C

MR6-C

MR10-G24-C

MR10-C

MR10-RGB24-C

This manual contains important information regarding your MOTAK unit. Please read the

manual thoroughly prior to equipment set-up, operation and maintenance. Failure to comply

with regular maintenance guidelines outlined in the manual may void the warranty. Improper

installation, adjustment, alteration, service or maintenance can cause property damage, injury

or death. Read this manual thoroughly before installing or servicing this equipment.

MUST READ!

Table of Contents

Questions and Answers

A
amyreedAug 5, 2025
What to do if the pilot flame is on, but the main burner will not ignite on my Motak Ranges?
- K
  Kristin MilesAug 5, 2025
  If the pilot flame is on but the main burner on your Motak Ranges won't ignite, it could be due to several reasons. First, the gas pressure might be insufficient; in this case, adjust the pressure regulator to the proper pressure setting using a manometer, referring to the data tag. Alternatively, the main burner orifice could be blocked, requiring you to unblock it. A defective gas control valve could also be the culprit, necessitating its replacement. Finally, an incorrect by-pass setting could be the cause, so try resetting it.
R
Robin TurnerAug 12, 2025
Why the pilot flame cannot be ignited on my Motak MR4-C-S Ranges?
- K
  Kenneth MillerAug 12, 2025
  If the pilot flame on your Motak Ranges cannot be ignited, several factors could be responsible. First, the gas pressure might be insufficient, requiring you to adjust the pressure regulator to achieve proper pressure. Second, the nozzle might be blocked, so try unblocking it. A loose thermocouple connection could also be the reason; ensure you tighten it. If the thermocouple is defective, it will need replacement. Lastly, a malfunctioning gas control valve may be the cause, necessitating its replacement.
O
oesparzaAug 20, 2025
How to fix burners with yellow tips and black soot on Motak MR4-C-S Ranges?
- Z
  zvelezAug 20, 2025
  If the burners on your Motak Ranges have yellow tips and are creating black soot, it could be due to several reasons. The burner orifice might not be the correct size for the type of gas being supplied, so check the orifice size to ensure it is correct for the gas supply. Also, the air shutter might not be adjusted properly, so adjust the air shutter on the burner. Insufficient gas pressure could be a factor, so use a manometer to adjust the pressure regulator to the proper pressure setting on the data tag. Finally, the volume of gas being supplied might be too low; verify that the connection type is at least ¾” inside diameter and of commercial grade, and check with your installer for correction.
Y
ylivingstonAug 28, 2025
What to do if Motak MR4-C-S Ranges burner has a “Pop” sound when gas supply is turned off?
- O
  ogrossAug 28, 2025
  If your Motak Ranges burner makes a “Pop” sound when the gas supply is turned off, there are several potential causes. The burner orifice might not be the correct size for the type of gas being supplied; in this case, check the orifice size to be sure it is correct for the gas supply. Alternatively, the air shutter might not be adjusted properly; adjust the air shutter on the burner. Insufficient gas pressure could also be the cause; use a manometer to adjust the pressure regulator to the proper pressure setting on the data tag. Lastly, the gas supply connection might not be the correct size; verify that the connection type is at least ¾” inside diameter and of commercial grade, and check with your installer for correction.

Summary

CODES AND STANDARDS

SPECIFICATIONS

INSTALLATION

PRECAUTIONS & RECOMMENDATIONS

Gas Leak Detection and Safety Cautions

Crucial safety steps for gas leak detection and general operating precautions.

OPERATION

Control Panel Overview

Explains the layout and function of the control panel.

Top Burner Operation

Step-by-step guide for igniting and adjusting top burners.

Griddle Operation and Seasoning

Covers pilot lighting, griddle seasoning, and preheating procedures.

OPERATING THE OVEN

Oven Ignition and Burn-Off

Procedures for igniting the oven pilot and initial burn-off.

Oven Thermostat Adjustment

Details the by-pass setting for proper oven thermostat calibration.

ROUTINE INSPECTION

CLEANING & MAINTENANCE

General Cleaning Guidelines

Instructions for cleaning stainless steel surfaces and general components.

Cast Iron Grate Cleaning

Steps to remove rust from cast iron grates and proper cleaning.

Griddle Cleaning Procedures

Detailed steps for cleaning the griddle plate, body, and catch tray.

TROUBLE SHOOTING

Pilot and Burner Ignition Issues

Solutions for pilot flame failure and main burner ignition problems.

Burner Performance Issues

Addresses burner flame quality, soot, and gas supply problems.
