RUNNING
IN
After
the
first
500 kms.
[300 mli'es)
Every
500
kms.
(300
miles)
During the
first
t600 kms.
(tOOO
miles).
a
new
or
overhauled machine ought
to
be used
with
some inte
llig
ence
as
the efficiency. per-
formanco. and
lile
of
the eng
in
e are largely
dependant on how
It Is run in.
Th
e engine sho
uld
never be all
owe
d to reach
a high number
01 revolutions
befor
e
it
has
had a chance
to
warm
up
suffi
cientl
y.
Never
ride the machine at the highest
permissi
ble
speeds
for
each gear
belore
the machine has
been
we!1
broken in.
Should the engine speed
drop
off
considera-
bly on
an
uphill
grade. a
lower
gear should
be
Immediately engaged.
In
case
of
overheat-
ing. It is best to stop and
allow
the engine
to cool down.
Under no Circumstances
whatever
should the
following
speeds be exceeded in the running
in period . .
Maximum
permissible
speeds:
Distance:
up
to
800
kms.
(SOO
miles):
in
low
gear
45
kms.
128
miles)
in second
gear
65
kms. (40
miles)
in third
gear
85
kms. [53 miles)
in fourth gear
100
kms. [62
miles)
in top gear
115
kms. (72
miles)
from
800
to
1600 kms. (500
to
1000
miles)
:
in
low
gear
55
kms.
(34
.5
miles)
in
second
gear
80
kms. [50
miles)
in
third. gear
105
kms. [65
miles}
in
fourth
gear 120 kms (75 mil
es
)
in top gear
140
kms. (87.5
miles)
From
1600
to
3000
kms. (1000 to
1800
miles)
the speed can be gradually increased up
to
the maximum
permissible
limits.
.
Change the engine
oil.
Tighten all nuts and
bolts.
Check valve clearance.
Check
distributor
pOints.
Check
oil
level.
Correct
level is in between
the
minimum
and maximum mark on the
filler
cap
dipstick.
