MOTORGUIDE WIRELESS
90-MM5981 For Questions, Contact Consumer Affairs at #1-920-929-5040 15
© 2005, MotorGuide www.motorguide.com
of six (6) gauge (13 mm) wires if extending the existing wire beyond the
standard battery cable supplied with the product.
Bow Plugs – MotorGuide recommends the use of a quality plug designed
12 Volt Battery Hook-up
) Blac ) Jumper Wire
To trolling r
ower ctions
onnect the red battery lead from the power cable to the battery positive (+)
-)
for marine applications.
A Dk battery lead (-)
B) Red battery lead (+)
C) 50 amp circuit E)
Breaker and a p motor conne
switch
C
post and the black battery lead from the power cable to the battery negative (
post. Install a 50 amp circuit breaker and a power switch in line with the
positive lead as shown in C above. (See the “Assessories” section in this
manual for the circuit breaker and power switch part number.)
O
WARNING
!
D
b when connecting the motor to the serve installation guidelines
batteries. When in doubt, consult a professional at your nearest
dealer.
Always connect to the battery through a power plug which can
be easily disconnected or through an easily accessible power
switch. Never “hardwire” the motor directly to the batteries.
Always use the recommended circuit breaker to protect the
wires.
