MotorGuide Wireless Series - Maintenance; Foot-Pedal Battery Replacement

MOTORGUIDE WIRELESS
90-MM5981 For Questions, Contact Consumer Affairs at #1-920-929-5040 21
© 2005, MotorGuide www.motorguide.com
MAINTENANCE
Foo lacement
ollow these instructions to change
2. Remove the battery cover pl
3. Using a pencil, push the battery out of its holder.
5. Ensure the O- ring is in
place on the inside
cover. Replace the cover
plate and five screws.
t-Pedal Battery Rep
Use only a 3V lithium type CR2032
replacement battery. These
atteries are not rechargeable. b
F
the battery:
1. Remove the five screws
on the battery cover plate
located on the underside
of the foot-pedal.
ate.
4. With the “+” symbol facing up, slide
the new battery in the holder.
Location of Screws Securing Battery
Cover Plate to Foot-Pedal
