MOTORGUIDE WIRELESS
8M4000137 For Questions, Contact Consumer Affairs at #1-920-929-5040 20
© 2005, MotorGuide www.motorguide.com
Operating the Foot-Pedal
INFORMATION
On/Off Button
Faster Button Slower Button
Left Button Right Button
Ensure the foot-pedal electronic ID has been activated. See the “Installation”
section of this manual for instructions.
1. Prop On/Off
Turn the prop on or off by pressing the
center button and it will alternate
between on and off. The “on” condition is
indicated by a short beep while “off” is
indicated by a long beep.
2. Steering: Press the left or right arrow buttons to steer the boat. Each
button press steers the motor left or right one step; holding down a button
will rapidly steer the motor in the direction of the selected arrow.
3. Speed: Use the + and – buttons to control the motor speed, a beep will
sound each time the + or – buttons are pushed. Holding the button down
will rapidly speed-up or slow-down the motor until it reaches minimum or
maximum speed; once at the limit, the receiver will no longer beep when
you press a button.
