Chapter 1
About the Charger
The Motorola Solutions Tri-Chem Rapid Charger (PMLN5228_) allows the drop-in charging of the
battery while attached to the radio or separately.
1.1
Charger Specification
The following table lists the input and output voltage of the charger.
Table 1: Charger Specification
Component Voltage
Input 14 V 1 A
Output 11.2 V 850 mA
Battery Charging Temperature
To ensure a successful charging process, it is recommended to maintain the battery temperature
between 5 °C to 40 °C.
To get maximum use from a new battery, charge it overnight (12–16 hours) before using the battery for
the first time.
For optimum charger performance, perform the following actions:
• Charge battery at 20 °C to 25 °C ambient temperatures.
• Turn off the radio, if attached.
NOTE: The estimated time required to fully charge the discharged battery is typically within 2–4
hours depending on cell chemistry.
MN010023A01-AB
About the Charger
9
