Motorola AM21 - Page 3

Overview of the Parent Unit
2
1
5
3
6
7
4
8
1. Power/Link indicator
On when the parent unit is
powered on and linked to
the baby unit.
Flashes when the parent
unit is searching the baby
unit.
2. Microphone
3. LEFT button
<
Press to decrease the
speaker volume.
4. RIGHT button
>
Press to increase the
speaker volume.
5. Power button
0
Press and hold to power on/
o the parent unit.
6. Battery cover
7. Speaker
8. Power jack
