14 AP6522 Access Point
9. Attach an Ethernet cable from the access point to a controller with an 802.3af compatible power source.
10. Verify the access point is receiving power by observing that the LEDs are lit or flashing.
2.6.3 Wall Mount Procedure - Existing Access Point Replacement
An existing external antenna model AP300 (WSAP-5100-100) or external antenna model AP650 (AP-0650-660X0)
access point, installed on a wall (plenum installation), can be placed by an AP6522. Simply remove the existing
legacy model access point from its mounting screws, leave the mounting hardware in place and install the new
external antenna model AP6522 directly on to the existing mounting hardware. The cabling procedure for such a
replacement is as described in the previous section.
CAUTION If not using a 802.3af capable controller to power the AP6522, ensure
only the AP6522’s designated power supply (PWRS-14000-148R) is
used to supply power to the access point. Using an incorrectly rated
power supply could damage the unit and void the product warranty.
Do not actually connect to the power source until the cabling portion
of the installation is complete.
!
