5 Accessory Connector
6 Home Button
7 4–Way Navigation Button
8 Battery Latch
9 Keypad
10 Data Feature Button
11 Menu Select Buttons
12 Main Display
13 2–Position Concentric Switch
[1]
14 3–Position A/B/C Switch
[1]
15 On/Off/Volume Control Knob
16 Top Side (Select) button
[1]
17 Push-to-Talk (PTT) Button
18 Side Button 1
[1]
19 Side button 2
[1]
20 Battery
21 Bluetooth Pairing Location Indicator
22 Main Speaker
23 Microphone
24 Top Display
25 16–Position Select Knob
[1]
Programmable Features
Any reference in this manual to a control that is
preprogrammed means that the control must be
programmed by a dealer or qualified radio technician
using the radio programming software, in order to
assign a feature to that control.
The programmable buttons can be programmed as
shortcuts to radio functions or preset channels/groups
depending on the duration of a button press:
Press Pressing and releasing rapidly.
1
These radio controls/buttons are programmable.
Identifying Radio Controls
28
