2
Rotate and lift the connector cover to disengage it
from the radio.
3
To attach the accessory connector cover, insert
the hooked end of the cover into the slot above
the connector.
4
Press downward on the cover’s top to seat it in the
slot.
5
Once in place, tighten by rotating the thumbscrew
clockwise by hand.
Attaching the Belt Clip
1
Align the grooves of the belt clip with those of the
radio and press upward until you hear a click to
attach the belt clip.
2
Use a flat-bladed object to press the belt clip tab
away from the radio. Then, slide the clip
downward and away from the radio to remove the
clip.
Preparing Your Radio for Use
21
English
