Chapter 2
Getting Started
This section helps you to get familiar with the basic operations of the radio.
2.1
Installing the Li-Ion Battery
Procedure:
1 Slide the latch at the top of the battery door to the unlock position, and lift the battery door at the
center recess.
a Align the battery contacts with the tabs in the battery compartment. Insert the contact side of
the battery first, then press the battery down to secure in place.
Figure 2: Attaching the Battery
2 Put the battery door back on the radio.
3 Slide the latch to the lock position.
2.2
Removing the Li-Ion Battery
Procedure:
1 Turn the radio off.
2 Slide the latch at the top of battery door to the unlock position, and lift the battery door at the
center recess.
Figure 3: Removing a Li-Ion Battery
3 Pull the battery removal tab until the battery is disengaged from the battery compartment.
4 Pull the battery away from the radio.
MN007428A01-AB
Chapter 2: Getting Started
14
