1-2 MODEL CHART AND TECHNICAL SPECIFICATIONS
2.0 Technical Specifications
Data is specified for +25°C unless otherwise stated.
General
Specification UHF1
Frequency Range: 403-440 MHz
Frequency Stability
(-30°C to +60°C, 25°C Ref.)
±2.5 PPM
Channel Capacity: CM160 - 64
Channel Spacing: 12.5/25 kHz
Power Supply: 13.6 Vdc (10.88 Vdc - 16.32 Vdc) negative Vehicle
ground
Dimensions (L x W x H)
4.65” X 6.67” X 1.73”
(118mm X 169.5mm X 44mm)
Weight 2.22 lbs (1.01 kg)
FCC Description ABZ99FT4064
Operating Temperature -30 to 60° C (Display only -20°C to 60°C)
Storage Temperature -40 to 85° C
Thermal Shock -40 to 80° C
High Humidity 95% RH @ 50° C for 8 hrs
ESD 15KV air discharge
Packing Test Impact Test
