Motorola CM200 - Page 216

4-24 UHF 25-40 W Band 2 PCB 8486577Z01 / Schematics
C5092 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5094 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5095 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5096 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5097 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5098 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5099 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5100 2113740F59 CAP CHIP REEL CL1 +/-30
220
C5101 2113741F25 CAP CHIP CL2 X7R REEL
1000 (not used in GM3188)
C5102 2113743E20 CAP CHIP. 10 UF 10%
(not used in GM3188)
C5103 2113743K15 CHIP CAP, CER 0.1UF
(not used in GM3188)
C5104 NOT PLACED GCAM DUMMY PART NUM-
BER
C5110 2113741F25 CAP CHIP CL2 X7R REEL
1000
C5111 2113741F25 CAP CHIP CL2 X7R REEL
1000
C5113 NOT PLACED GCAM DUMMY PART NUM-
BER
C5114 NOT PLACED GCAM DUMMY PART NUM-
BER
C5115 NOT PLACED GCAM DUMMY PART NUM-
BER
C5116 NOT PLACED GCAM DUMMY PART NUM-
BER
C5117 NOT PLACED GCAM DUMMY PART NUM-
BER
Circuit
Ref.
Motorola
Part No.
Description
C5118 NOT PLACED GCAM DUMMY PART NUM-
BER
C5119 2113743H14 CAP CHIP 10.0 UF 16V +80-
20%
C5120 NOT PLACED GCAM DUMMY PART NUM-
BER
C602 2113740F41 CAP CHIP REEL CL1 +/-30
39
C603 2113740F41 CAP CHIP REEL CL1 +/-30
39
C604 2113740F41 CAP CHIP REEL CL1 +/-30
39
C605 2113740F41 CAP CHIP REEL CL1 +/-30
39
C606 2113740F41 CAP CHIP REEL CL1 +/-30
39
C607 2113740F41 CAP CHIP REEL CL1 +/-30
39
C608 NOT PLACED GCAM DUMMY PART NUM-
BER
C609 NOT PLACED GCAM DUMMY PART NUM-
BER
C610 2113740F41 CAP CHIP REEL CL1 +/-30
39
C611 2113740F41 CAP CHIP REEL CL1 +/-30
39
C612 2113740F41 CAP CHIP REEL CL1 +/-30
39
C613 2113740F41 CAP CHIP REEL CL1 +/-30
39
C614 2113740F41 CAP CHIP REEL CL1 +/-30
39
C615 2113740F41 CAP CHIP REEL CL1 +/-30
39
C616 2113740F41 CAP CHIP REEL CL1 +/-30
39
C617 2113740F41 CAP CHIP REEL CL1 +/-30
39
Circuit
Ref.
Motorola
Part No.
Description
C618 2113740F41 CAP CHIP REEL CL1 +/-30
39
C619 NOT PLACED GCAM DUMMY PART NUM-
BER
C620 2113740F41 CAP CHIP REEL CL1 +/-30
39
C621 2113740F41 CAP CHIP REEL CL1 +/-30
39
C622 2113740F41 CAP CHIP REEL CL1 +/-30
39
C623 2113740F41 CAP CHIP REEL CL1 +/-30
39
C624 2113740F41 CAP CHIP REEL CL1 +/-30
39
C625 2113740F41 CAP CHIP REEL CL1 +/-30
39
C626 2113740F41 CAP CHIP REEL CL1 +/-30
39
C627 2113740F41 CAP CHIP REEL CL1 +/-30
39
C628 2113740F41 CAP CHIP REEL CL1 +/-30
39
C629 2113740F41 CAP CHIP REEL CL1 +/-30
39
C630 2113740F41 CAP CHIP REEL CL1 +/-30
39
C631 2113740F41 CAP CHIP REEL CL1 +/-30
39
C632 2113740F41 CAP CHIP REEL CL1 +/-30
39
C633 2113740F41 CAP CHIP REEL CL1 +/-30
39
C662 2113740F41 CAP CHIP REEL CL1 +/-30
39
C678 2113741M69 CAP CHIP CLS2 100000 PF
20V 1
CR300 4880154K03 SOT MMBD353 RH DIODE
DUAL SCH
Circuit
Ref.
Motorola
Part No.
Description
CR301 4880154K03 SOT MMBD353 RH DIODE
DUAL SCH
D100 NOT PLACED GCAM DUMMY PART NUM-
BER
D101 NOT PLACED GCAM DUMMY PART NUM-
BER
D102 4813833C02 DIODE DUAL 70V ‘5B’
COMM CATH
D103 4802482J02 PIN DIODE SMD
D104 4802482J02 PIN DIODE SMD
D105 4805218N57 DIODE DUAL
D106 4805218N57 DIODE DUAL
D107 4805218N57 DIODE DUAL
D108 4805218N57 DIODE DUAL
D200 4802233J09 DIODE TRIPLE SOT25-RH
D201 4802233J09 DIODE TRIPLE SOT25-RH
D202 4862824C03 DIODE VARACTOR
D203 4805649Q13 DIODE VCTR ISV 228
D204 4805649Q13 DIODE VCTR ISV 228
D205 4862824C01 DIODE VARACTOR
D301 4802245J97 Band Switchind Diode, Rohm
DA
D302 4802245J97 Band Switchind Diode, Rohm
DA
D303 4802245J97 Band Switchind Diode, Rohm
DA
D304 4802245J97 Band Switchind Diode, Rohm
DA
D305 4880142L01 SOT MMBV109 RH
D400 4813833C07 DIODE DUAL 100V ‘5C’
SERIES
D401 4813833C02 DIODE DUAL 70V ‘5B’
COMM CATH
D402 4809948D42 DIODE SCHOTTKY RB751V-
40
Circuit
Ref.
Motorola
Part No.
Description
