Motorola CM360 Service Information

4-26 VHF1 1-25W PCB 8486672Z01 / Schematics
R5041 0662057A82 CHIP RES 24K OHMS 5%
R5042 0662057A82 CHIP RES 24K OHMS 5%
R5043 0662057A82 CHIP RES 24K OHMS 5%
R5044 0662057A82 CHIP RES 24K OHMS 5%
R5045 0662057A85 CHIP RES 33K OHM 5%
R5046 0662057A82 CHIP RES 24K OHMS 5%
R5047 0662057B47 CHIP RES 0 OHMS +-.050
OHMS (CM160/CM360 only)
R5048 0662057A82 CHIP RES 24K OHMS 5%
R5049 0662057A77 CHIP RES 15K OHMS 5%
R5050 0662057A76 CHIP RES 13K OHMS 5%
R5051 0662057A75 CHIP RES 12K OHMS 5%
R5052 0662057A73 CHIP RES 10K OHMS 5%
R5053 0662057A73 CHIP RES 10K OHMS 5%
R5054 0662057A73 CHIP RES 10K OHMS 5%
R5055 0662057A73 CHIP RES 10K OHMS 5%
R5056 0662057A73 CHIP RES 10K OHMS 5%
R5057 0662057A73 CHIP RES 10K OHMS 5%
R5058 NOT PLACED GCAM DUMMY PART NUMBER
R5059 NOT PLACED GCAM DUMMY PART NUMBER
R5060 0662057A73 CHIP RES 10K OHMS 5%
R5061 0662057A73 CHIP RES 10K OHMS 5%
R5062 0662057A73 CHIP RES 10K OHMS 5%
R5063 NOT PLACED GCAM DUMMY PART NUMBER
R5064 NOT PLACED GCAM DUMMY PART NUMBER
R5065 0662057A68 CHIP RES 6200 OHMS 5%
R5066 0662057A49 CHIP RES 1000 OHMS 5%
R5067 NOT PLACED GCAM DUMMY PART NUMBER
R5068 NOT PLACED GCAM DUMMY PART NUMBER
R5069 0662057A73 CHIP RES 10K OHMS 5%
R5070 0662057A57 CHIP RES 2200 OHMS 5%
R5071 0662057A57 CHIP RES 2200 OHMS 5%
Circuit
Ref.
Motorola
Part No.
Description
R5072 0662057A65 CHIP RES 4700 OHMS 5%
R5073 0662057A49 CHIP RES 1000 OHMS 5%
R5074 0662057A49 CHIP RES 1000 OHMS 5%
R5075 0662057A42 CHIP RES 510 OHMS 5%
R5076 0662057A42 CHIP RES 510 OHMS 5%
R5077 0662057A36 CHIP RES 300 OHMS 5%
R5078 0662057A25 CHIP RES 100 OHMS 5%
R5079 0662057A25 CHIP RES 100 OHMS 5%
R5080 0662057A01 CHIP RES 10 OHMS 5%
R5081 0613952D78 CER CHIP RES 6340 OHM 1%
0603
R5082 0662057A90 CHIP RES 51K OHMS 5%
R5083 0662057B08 CHIP RES 270K OHMS 5%
R5084 0662057B47 CHIP RES 0 OHMS +-.050
OHMS (CM160/CM360 only)
R5085 NOT PLACED GCAM DUMMY PART NUMBER
R5086 0662057A43 CHIP RES 560 OHMS 5%
R5087 0662057A97 CHIP RES 100K OHMS 5%
R5088 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R5089 NOT PLACED GCAM DUMMY PART NUMBER
R5092 0662057A73 CHIP RES 10K OHMS 5%
R5093 0662057A73 CHIP RES 10K OHMS 5%
R5094 NOT PLACED GCAM DUMMY PART NUMBER
R5095 0662057A82 CHIP RES 24K OHMS 5%
R5096 0662057A73 CHIP RES 10K OHMS 5%
R5097 NOT PLACED GCAM DUMMY PART NUMBER
R5098 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R5099 NOT PLACED GCAM DUMMY PART NUMBER
R5100 NOT PLACED GCAM DUMMY PART NUMBER
R5101 0662057A25 CHIP RES 100 OHMS 5%
R5102 0662057A25 CHIP RES 100 OHMS 5%
R5103 NOT PLACED GCAM DUMMY PART NUMBER
Circuit
Ref.
Motorola
Part No.
Description
R600 0662057C01 CHIP RES 0 OHMS .050 OHMS
R601 0611077A62 RES CHIP 330 5 1/8W
R602 0662057B47 CHIP RES 0 OHMS +-.050
OHMS
R603 0662057C01 CHIP RES 0 OHMS .050 OHMS
R604 0662057C01 CHIP RES 0 OHMS .050 OHMS
R610 0662057C59 CHIP RES 220 OHMS 5%
R615 0662057A25 CHIP RES 100 OHMS 5%
RT100 0680361L01 THERMISTOR 47KOHM
S5010 1889288U01 POTENTIOMETER W/SWITCH
VOLUME
SH200 2689590U01 VCO SHIELD
SH201 2689589U01 VCO SHIELD
SH202 2689589U01 VCO SHIELD
SH300 2689591U01 MIXER SHIELD
SH301 2689593U01 FRONT ENA SHIELD
SH302 2689591U01 MIXER SHIELD
T300 2580541Z01 BALUN TRANSFORMER
T301 2580541Z01 BALUN TRANSFORMER
U100 5113818A01 IC LOW COST SING SPLY
LM2904DR
U101 5185130C65 IC VHF/UHF/800 MHZ LDMOS
DRIVE
U102 5113818A01 IC LOW COST SING SPLY
LM2904DR
U103 5113819A04 IC QD OP AMP GEN PURP
MC3303D
U200 5185963A27 IC TESTED AT25016 48 PIN
GFP
U201 5105750U54 IC PKG DIE VCO BUFFER
U300 5186144B01 FM IF IC SA616
U301 5109522E10 IC 3-INV LMOS TC7W04FU
U302 4808612Y05 CROSSOVER QUAD DIODE
SMS3928-0
U400 5102463J64 16KX8 SPI SERIAL EEPROM
Circuit
Ref.
Motorola
Part No.
Description
U402 NOT PLACED GCAM DUMMY PART NUMBER
U403 5102226J56 68HC11FLO_PASS5 100P IN
TQFP
U404 5189233U02 FLASH 2MEG AT49LV002N-70VI
U405 5113805A75 IC 8 BIT SER TO PAR/PAR
HC595
U500 5113818A01 IC LOW COST SING SPLY
LM2904DR
U501 0104016J81 9V REGULATOR ASSEMBLY
U502 5102463J95 AUDIO PA TDA1519C
U503 5105469E65 IC VLTG REGLTR
U504 5185130C53 IC ASFIC_CMP_R1
U505 5113818A01 IC LOW COST SING SPLY
LM2904DR
U506 5113818A01 IC LOW COST SING SPLY
LM2904DR
U507 5113818A01 IC LOW COST SING SPLY
LM2904DR
U508 5113816A30 IC 3.3V LOW DROPOUT POS.
REG.
U509 5113806A20 IC MUX/DEMUX TRIPLE 2-
CHNL
U510 5104187K94 IC LP2986ILDX-3.3 VLTG REG
U514 4802393L66 MOSFET P-CH
U515 5162852A59 IC CMOS ANALOG SWITCH
SPDT (CM160/CM360 only)
VR101 4813830A15 TSTR 5.6V 5% 20MA 225MW
VR102 4813830A15 TSTR 5.6V 5% 20MA 225MW
VR400 NOT PLACED GCAM DUMMY PART NUMBER
VR401 4813830G12 DIODE 4.3V 5% ‘CP’ 500MW
_4687
VR402 4813830A09 DIODE 3.3V 5% 225MW
MMBZ5226B
VR500 4813832C77 TRANS SUP. 24V HIGH PWR
VR501 4813830A14 DIODE 5.1V 5% 225MW
MMBZ5231B_
VR502 NOT PLACED GCAM DUMMY PART NUMBER
Circuit
Ref.
Motorola
Part No.
Description
