Overview of the Parent Unit
1. Display (LCD screen)
2. Charging LED
RED when mains power connected.
3. Parent Unit ON/OFF LED (Green)
4. Audio Level LEDs (Green, Green,
Amber, Red)
5. Volume Down
Press to decrease Volume level.
6. Volume Up
Press to increase Volume level.
7. Microphone
8. Display ON/Microphone
9. MENU button
Press to open / close the Menu
options.
10. Navigation button
Move Up/Down/Right/Left menu
options.
11. OK button
12. TALK button
Press and hold to speak to
your baby.
13. Power button
Press and Hold to turn the Parent
Unit ON/OFF.
VIDEO ON/OFF button
Press to turn the LCD screen
ON/OFF (Note: audio is
maintained.)
14. RESET button (recessed - use
small pin)
15. Power Socket
16. Stand
17. Speaker
1 2 3 4 5 6 7
14
15
8
9
11
10
12
13
16
17
