Disassembly/Reassembly Procedures: Radio Disassembly – Detailed 5-15
5. Lift the option board with flex from the front kit.
Figure 5-10. Option Board Disassembly
6. Gently lift the connector actuator on the option board to release the flex.
7. Remove the flex from the connector by pulling it out of its connector gently.
Figure 5-11. Flex Removal
