Motorola DP1400 Series

Disassembly/Reassembly Procedures: Radio Disassembly – Detailed 5-21
b. Cut off the head from the inside of the housing with cutter as Figure 5-17.
Figure 5-17. Micro USB Dust Cover Removal
c. Separate the dust cover from the front housing.
NOTE
Micro USB dust cover is non-serviceable. Replace with a new one during reassembly.
Top Tab
Head
Inside of front housing
