BATTERIES AND CHARGER
English
Charging the Battery
To charge the battery (with the radio attached),
place it in a Motorola-approved Drop-in Tray
Single Unit Charger or Drop-in Tray Multi Unit
Charger.
Note: When acquiring additional chargers or
power supplies, make sure you have similar
drop-in tray chargers and power supplies
sets (all “rapid” or all “standard”). For part
number details, refer to “Chargers” on
page 161
Charging with the Drop-in Tray
Single Unit Charger (SUC)
1. Place the drop-in tray charger on a flat surface.
2. Insert the connector of the power supply into the
port on the side of the drop-in tray charger.
3. Plug the AC adaptor into a power outlet.
4. Insert the radio into the tray with the front of the
radio facing the front of the charger, as shown.
When charging a battery attached to a radio,
turn the radio OFF to ensure a full charge. See
“Operational Safety Guidelines” on page 115
for more information
Power Supply
(Transformer)
Drop-in Tray Charger
Drop-in Tray
Charger Port
