3-2 SERVICE AIDS
2.0 Test Equipment
Table 3-2 lists test equipment required to service the radio and other two-way radios.
Table 3-2 Recommended Test Equipment
Motorola Part
Number
Description Characteristics
Application
R2600_NT Comms System Analyzer
(non MPT)
This monitor will
substitute for items
with an asterisk*
Frequency/deviation
meter and signal
generator for
widerange
troubleshooting and
alignment
R2680_NT Comms System Analyzer
( MPT1327) to be ordered
with
RLN1022_ (H/W)
RLN1023_ (S/W)
This monitor will
substitute for items
with an asterisk*.
Frequency/deviation
meter and signal
generator for
widerange
troubleshooting and
alignment
*R1072_ Digital Multimeter AC/DC voltage and
current
measurements
*R-1377_ AC Voltmeter 100µV to 300V, 5Hz -
1MHz, 10Megohm
input impedance
Audio voltage
measurements
WADN133 Delay Oscilloscope 2 Channel 40MHz
bandwidth,
5mV/cm - 20 V/cm
Waveform
measurements
R1440_
0180305F17
0180305F31
0180305F39
RLN4610
T1013_
Wattmeter,
Plug-in Elements
Plug-in Elements
Plug-in Elements
Carry case
RF Dummy Load
Thruline 50-Ohm,
±5% accuracy
100W, 25 - 60MHz
25W, 100-250MHz
10W, 200-250MHz
Wattmeter and
6 elements
Transmitter power
output
measurements
S1339_ RF Millivolt Meter 100mV to 3 VRF.
10kHz to 1.2GHz
RF level
measurements
R1011_/220V 220V Power Supply 0 - 40V 0 - 40A Programmable
