1-12 INSTALLATION
5.3.4 To Install the Remote Controlhead:
1. Position the Remote Mount Bracket (Item2 in Figure 1-8 Remote Front and Back Housings) in
the desired location and mark the positions of the mounting holes.
2. Centrepunch the marked spots and drill 4mm holes at each spot.
3. Fix the Remote Mount Bracket in position using the supplied screws.
4. Route the Remote Cable (Table 1-3) as required, feeding it through the bracket
(a 20mm hole is required for the cable plug).
5. Push the cable plug into the Remote Front and Back Housing until it snaps into place.
6. Snap the assembly into the bracket.
7. Adjust the assembly as required then fix it in position with the wing screws supplied.
Table 1-3 Associated Components
Item Description Part Number
1 Wingscrews 0305760W02
2 Remote Bracket 0764275B01
3 Remote Back Housing
(GM380/GM1280)
Remote Back Housing
(GM340/GM360/GM640/GM660)
1564268B01
1564269B01
4 Remote PCB (2 off per kit) GLN7362
5 Flex (2 off per kit) 8486127B01
6CableKit3M
Cable Kit 5M
Cable Kit 7M
RKN4077*
RKN4078*
RKN4079*
7 Remote (Transceiver) Front Housing 1564270B01
8 Dismantling Tool 6686119B01
* Cable Kits to be ordered separately.
NOTE
Specifications are subject to change without notice.
Contact your Motorola dealer for the latest specifications.
