Accessory Connections 1-15
6.2 Accessory Connection Plan
CAUTION: The accessory connections shown are not compatible to some other models of
Motorola radios. Check the appropriate accessory or technical manual for further
information. Ensure correct position of the accessory connector.
CAUTION: DO NOT short pin 16 or 1 on the accessory connector to ground; this may
damage the radio.
!
1816141210
1715
13119753
1
19
864220
86
85
87
30
+12V
Ext. Alarm 4
86
85
87
30
+12V
Ext. Alarm 4
+12V
+12V
SWB+ 13
4A
+12V
Ignition 10
1
16
GND 7
MIC 2
PTT 3
GND 7
Emergency 9
12k
GND 7
Alarm
Relay
Alarm
Relay
GKN6272 External Alarm, Relay and Cable
RSN4001 Speaker 13W
HSN8145 Speaker 7,5W
RMN4027 Visor mounted Microphone
RLN4856 Footswitch w/Remote PTT
RLN4857 Pushbutton w/Remote PTT
RLN4858 Gooseneck PTT
RLN4836 Tri-State Emergency
Footswitch and Cable
Ignition
Switch
Ignition Sense
"on - off"
HKN9327 Ignition Switch CBL
* Note the location of pin 1.
!

Motorola GM Series Specifications

General

Channels	16
Waterproof	No
Frequency Range	VHF: 136-174 MHz
Signaling	DTMF, MDC1200
Dimensions	56 x 175 x 218 mm
