Motorola GM950i

216-246MHz Voltage Controlled Oscillator Schematic Diagram
6.4-16 Diagrams and Parts Lists
Voltage Controlled Oscillator
Parts List
Circuit
Ref
Motorola
Part No.
Description
C3731 2113741F25 1nF 50V
C3733 2113740F25 8.2pF 5% 50V
C3734 2113740F03 1pF 5% 50V
C3735 2113741F17 470pF 50V
C3736 2113740F33 18pF 5% 50V
C3737 2113740F03 1pF 5% 50V
C3738 2113740F40 36pF 5% 50V
C3739 2113740F21 5.6pF 5% 50V
C3740 2113740F21 5.6pF 5% 50V
C3743 2113743K15 100nF 16V
C3744 2113741F25 1nF 50V
C3745 2113741F17 470pF 50V
C3751 2109720D01 LOW DIST 10nF
C3752 2113740F34 20pF 5% 50V
C3754 2113740F36 24pF 5% 50V
C3755 2113740F27 10pF 5% 50V
C3756 2113740F27 10pF 5% 50V
C3757 2113741F17 470pF 50V
C3758 2113741F25 1nF 50V
C3761 2113740F23 6.8pF 5% 50V
C3762 2113740F21 5.6pF 5% 50V
C3763 2113741F49 10nF 50V
C3764 2113740F21 5.6pF 5% 50V
C3765 2113740F29 12pF 5% 50V
C3766 2113740F51 100pF 5% 50V
C3767 2113741F49 10nF 50V X7R
C3771 2113743K15 100nF 16V
C3772 2113740F51 100pF 5% 50V
C3773 2113740F29 12pF 5% 50V
C3774 2113740F30 13pF 5% 50V
C3775 2113741F17 470pF 50V
C3777 2113741F17 470pF 50V
C3780 2113741F25 1nF 50V
C3781 2113741F49 10nF 50V
C3782 2113740F51 100pF 5% 50V
C3783 2113740F30 13pF 5%
C3784 2113740F27 10pF 5%
C3785 2113740F24 7.5pF 5%
C3790 2113740F32 16pF 5%
C3791 2113741F49 10nF 50V
C3792 2113741F49 10nF 50V
C3793 2113741F49 10nF 50V
C3801 2113743A23 220nF 16V
C3802 2113743E07 22nF 16V
C3803 2311049A63 TANT CP 10uF 10% 10V
D3731 4805649Q13 VCTR 1SV228 SOT23
D3732 4805649Q13 VCTR 1SV228 SOT23
D3733 4805649Q13 VCTR 1SV228 SOT23
D3739 4813825A05 MMBD301
D3751 4805649Q13 VCTR 1SV228 SOT23
D3752 4805649Q13 VCTR 1SV228 SOT23
D3754 4813825A05 MMBD301
E3731 2602641Y02 SHIELD, ARIANE VCO
E3732 2605915V01 SHLD PCB MOUNT
L3731 2462587T13 COIL CHIP 68nH
L3732 2462587T30 COIL CHIP 1uH
L3733 2462587T30 COIL CHIP 1uH
L3734 2462587N45 79 IDCTR, 22nH
L3741 2462587T30 COIL CHIP 1uH
L3742 2462587T30 COIL CHIP 1uH
L3750 2462587T30 COIL CHIP 1uH
L3751 2462587T30 COIL CHIP 1uH
L3752 2484562T11 AIR COIL 12.5nH
L3754 2462587T30 COIL CHIP 1uH
Circuit
Ref
Motorola
Part No.
Description
L3761 2462587T13 COIL CHIP 68nH
L3768 2462587T16 COIL CHIP 120nH
L3773 2462587N47 COIL CHIP 33nH
L3781 2462587T38 16 IDCTR, 22nH
L3783 2462587N50 COIL CHIP 56nH
Q3742 4805921T09 XSTR DUAL ROHM FMG8
Q3751 4813823A05 N-CH RF JFET
MMBU310LT1
Q3752 4880214G02 MMBT3904
Q3760 4813827A07 NPN SML SIG MMBR9
Q3770 4813827A07 NPN SML SIG MMBR9
Q3780 4813827A07 NPN SML SIG MMBR9
Q3790 4813827A07 NPN SML SIG MMBR9
R3731 0662057A21 68 1/16W 5%
R3739 0662057A83 27k 1/16W 5%
R3740 0662057A09 22 1/16W 5%
R3741 0662057A21 68 1/16W 5%
R3742 0662057A15 39 1/16W 5%
R3743 0662057A65 4k7 1/16W 5%
R3751 0662057A83 27k 1/16W 5%
R3752 0662057A57 2k2 1/16W 5%
R3753 0662057A25 100 1/16W 5%
R3754 0662057A15 39 1/16W 5%
R3761 0662057A53 1k5 1/16W 5%
R3762 0662057A41 470 1/16W 5%
R3763 0662057A29 150 1/16W 5%
R3765 0662057A35 270 1/16W 5%
R3766 0662057A09 22 1/16W 5%
R3794 NU NU
Circuit
Ref
Motorola
Part No.
Description
