Motorola GP series Detailed Service Manual

Controller Information 1-19
ModB/Vstby Supply
Under various conditions, the supply to the ModB/Vstby would vary. Table 7-2 shows these
conditions and circuits in operation.
Table 1-2: ModB/Vstby Supply Modes
Condition Circuit Operation
Vdd supply voltage via CR411
Radio Off • Vdd turned off
• Q416 gate is pulled low by R462
• Q416 is switched on
• U410 supplies 3.2V to ModB/Vstby
Primary battery removed • Vdd turned off
• Q416 gate is pulled low by R462
• Q416 is switched on
• LiO battery provides 3.2V to ModB/Vstby
Flash Mode • Boot_Ctrl line pull low
• ModA & ModB goes low
• Processor in boot-strap mode
• Flashing enabled

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
