Motorola GP series Detailed Service Manual

3-42 UHF PCB 8480587Z05 Parts List
C344 2113743M24 100000pF
C345 2113743M24 100000pF
C346 2113743M24 100000pF
C347 2113743M24 100000pF
C348 2113743M24 100000pF
C349 2113743E07 0.022uF
C350 2113743L05 330pF
C351 2113743N33 20pF
C352 2113743N28 12pF
C353 2113743N41 43pF
C354 2113743N42 47pF
C355 2113743A24 0.33uF
C356 2113743M08 22000pF
C357 2113743A23 0.22uF
C358 2113741A23 1200pF
C359 2109720D14 0.1uF
C360 2113743E07 0.022uF
C361 2113741F49 10000pF
C362 2113743M08 22000pF
C363 2311049A40 2.2uF
C364 2113743L41 10000pF
C370 2113743N50 100pF
C371 NOTPLACED
C372 NOTPLACED
C373 NOTPLACED
C374 2113743N50 100pF
C375 2113743N50 100pF
C378 NOTPLACED
C380 2113743L41 10000pF
C381 2113743N21 6.2pF
C382 2311049A59 10uF
C383 2113743N50 100pF
C384 2113743N44 56pF
C385 2113743N44 56pF
C386 2113743N50 100pF
C390 2113743N50 100pF
C391 NOTPLACED
C395 2113743N50 100pF
C396 NOTPLACED
C397 2311049A05 0.47uF
C400 2113743L41 10000pF
Circuit
Ref.
Motorola
Part No.
Description
C4001 NOTPLACED
C4002 NOTPLACED
C4003 NOTPLACED
C4004 NOTPLACED
C4005 NOTPLACED
C4007 NOTPLACED
C4008 NOTPLACED
C4009 NOTPLACED
C401 2113743M24 100000pF
C4010 NOTPLACED
C4011 NOTPLACED
C4012 NOTPLACED
C4013 NOTPLACED
C4014 NOTPLACED
C4015 NOTPLACED
C4016 NOTPLACED
C402 2113743M24 100000pF
C403 2113743G24 2.2uF
C404 NOTPLACED
C405 NOTPLACED
C406 NOTPLACED
C407 2113928N01 0.1uF
C408 2113743N50 100pF
C409 2113743M24 100000pF
C410 2113743M08 22000pF
C411 2113743M24 100000pF
C414 2113743M24 100000pF
C415 2185895Z01 0.01uF
C416 2113928N01 0.1uF
C419 NOTPLACED
C420 2113743L41 10000pF
C421 2113928N01 0.1uF
C422 2113743M24 100000pF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113743M24 100000pF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 100000pF
C429 2113743M24 100000pF
C430 2113928N01 0.1uF
Circuit
Ref.
Motorola
Part No.
Description
C431 2113743N50 100pF
C432 NOTPLACED
C433 2113743L41 10000pF
C434 2113928N01 0.1uF
C435 2113743M24 100000pF
C436 2113743N34 22pF
C437 2113743N34 22pF
C438 2113743L17 1000pF
C439 2113743L17 1000pF
C440 2113743G26 4.7uF
C441 2113743N50 100pF
C442 2113743E20 0.1uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 22000pF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C450 NOTPLACED
C451 2113743M08 22000pF
C452 2113743B29 1uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743N50 100pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C475 2113743H14 10uF
C476 2113928D08 10uF
C479 2113928N01 0.1uF
C480 2113928D08 10uF
C481 2113928N01 0.1uF
C482 2113928N01 0.1uF
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
Circuit
Ref.
Motorola
Part No.
Description
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47uF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 10000pF
C521 2113743L41 10000pF
C522 2113743L41 10000pF
C523 2113743L41 10000pF
C601 NOTPLACED
C602 NOTPLACED
C603 NOTPLACED
C701 2180478Z20 1uF
C702 2113928N01 0.1uF
C703 2113743N50 100pF
C704 2113928N01 0.1uF
C705 2113928N01 0.1uF
C706 NOTPLACED
C707 2113928N01 0.1uF
C708 2113928N01 0.1uF
C709 2113743L17 1000pF
C711 2113743L41 10000pF
C713 2113928N01 0.1uF
C714 2113928N01 0.1uF
C715 2113928N01 0.1uF
C717 2113928N01 0.1uF
C718 2113743L17 1000pF
C719 2113928N01 0.1uF
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diode
CR103 4802245J41 Pin Diode
CR105 5185963A15 Temperature Sensor
CR160 NOTPLACED
CR201 4802233J09 Triple Diode
CR203 4862824C03 Varactor
Circuit
Ref.
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
