UHF PCB 8415234H01 (EPP) Parts List 3-85
15.0 UHF PCB 8415234H01 (EPP)
Parts List
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 Connector (Contact Battery)
B503 3980502Z01 Contact, Backup B+
B504 3980501Z01 Contact, Backup B-
C101 2113944C45 CAP CER CHP 100.0PF 50V
5%
C102 2113944C72 CAP,FXD,6.2PF,.25PF+/-
,50V-DC,060
C103 2113944C30 CAP CER CHP 10.0PF 50V +/
- 0.5PF
C104 2113944C72 CAP,FXD,6.2PF,.25PF+/-
,50V-DC,060
C105 2113944A40 CAP CER CHP 100.0PF 50V
5%
C106 2113944C22 CAP CER CHP 4.7PF 50V +/-
0.25PF
C107 2113944C18 CAP CER CHP 3.3PF 50V +/-
0.25PF
C108 2113944A40 CAP CER CHP 100.0PF 50V
5%
C109 2113944C45 CAP CER CHP 100.0PF 50V
5%
C110 2113944A40 CAP CER CHP 100.0PF 50V
5%
C111 2113944C32 CAP CER CHP 15.0PF 50V
5%
C112 2180605Z32 Chip Capacitor, HIGH Q,
47PF
C113 2180605Z16 Chip Capacitor, HIGH Q,
10PF
C114 2113944A40 CAP CER CHP 100.0PF 50V
5%
C115 2115075H01 CAP,CERAMIC
CHIP,24PF,+5%,-5%,50V-
C116 2115075H01 CAP,CERAMIC
CHIP,24PF,+5%,-5%,50V-
C117 2113944A29 CAP CER CHP 22.0PF 50V
5%
C118 2113944A40 CAP CER CHP 100.0PF 50V
5%
C119 2113944A40 CAP CER CHP 100.0PF 50V
5%
C120 2113944A77 CAP,FXD,11PF,+5%,-5%,50V-
DC,0402,C
C121 2113944A40 CAP CER CHP 100.0PF 50V
5%
C122 2113944A40 CAP CER CHP 100.0PF 50V
5%
C123 2313960F04 CAP TANT 33 UF 10% 16V
6032-28
C125 2113944A40 CAP CER CHP 100.0PF 50V
5%
C126 2113946K02 CAP CER CHP 0.10UF 16V
C127 2113945A09 CAP CER CHP 1000PF 50V
10%
C128 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C129 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C130 2113944A40 CAP CER CHP 100.0PF 50V
5%
C131 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C132 2113944A40 CAP CER CHP 100.0PF 50V
5%
C133 2113945A09 CAP CER CHP 1000PF 50V
10%
C134 2113945A12 CAP CER CHP 3300PF 50V
10%
C135 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C138 2113944A40 CAP CER CHP 100.0PF 50V
5%
C140 0613952H91 CER CHIP RES 5600 OHM
5% 0603
C141 NOTPLACED -
C150 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C151 2113944A40 CAP CER CHP 100.0PF 50V
5%
C152 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
C160 2113944A40 CAP CER CHP 100.0PF 50V
5%
C161 2113946K02 CAP CER CHP 0.10UF 16V
C165 2113944A40 CAP CER CHP 100.0PF 50V
5%
C166 2113944A40 CAP CER CHP 100.0PF 50V
5%
C169 2113944A19 CAP CER CHP 5.6PF 50V +/-
0.5PF
C170 2113944A40 CAP CER CHP 100.0PF 50V
5%
C171 2113944A40 CAP CER CHP 100.0PF 50V
5%
C172 2113944C45 CAP CER CHP 100.0PF 50V
5%
C173 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,04
Circuit
Ref
Motorola
Part No.
Description
C174 2113944A40 CAP CER CHP 100.0PF 50V
5%
C175 2113944C45 CAP CER CHP 100.0PF 50V
5%
C201 2113944A40 CAP CER CHP 100.0PF 50V
5%
C202 2113945A09 CAP CER CHP 1000PF 50V
10%
C203 2113928L05 CAP CERAMIC CHIP 4.7 UF
C204 2113946N03 CAP CER CHP 2.2UF 16V
C206 2113944C04 CAP CER CHP 330.0PF 50V
5%
C207 2113944A33 CAP CER CHP 47.0PF 50V
5%
C208 NOTPLACED -
C210 2113944A40 CAP CER CHP 100.0PF 50V
5%
C211 2113944A40 CAP CER CHP 100.0PF 50V
5%
C212 2113944A40 CAP CER CHP 100.0PF 50V
5%
C213 2113944A40 CAP CER CHP 100.0PF 50V
5%
C214 2113944A40 CAP CER CHP 100.0PF 50V
5%
C217 2113946N03 CAP CER CHP 2.2UF 16V
C218 2113946K02 CAP CER CHP 0.10UF 16V
C219 2113946L03 CAP CER CHP 0.22UF 16V
C220 2113944A40 CAP CER CHP 100.0PF 50V
5%
C223 2113946K02 CAP CER CHP 0.10UF 16V
C224 2113946K02 CAP CER CHP 0.10UF 16V
C228 2313960D05 CAP TANT 4.7 UF 10% 16V
3528-21
C229 2113945A09 CAP CER CHP 1000PF 50V
10%
C230 2113944A40 CAP CER CHP 100.0PF 50V
5%
C231 2113946K02 CAP CER CHP 0.10UF 16V
C232 2113945D02 CAP CER CHP 47,000PF 25V
10%
C233 2313960A26 CAP TANT 0.1 UF 10% 35V
3216-18
C234 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C235 2113946N03 CAP CER CHP 2.2UF 16V
C238 2113945L17 CAP,FXD,470PF,+5%,-
5%,50V-DC,0603,
C241 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C242 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C243 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C244 2113944C13 CAP CER CHP 2.0PF 50V +/-
0.25PF
C245 2113944A10 CAP CER CHP 2.4PF 50V +/-
0.25PF
C246 2113944A40 CAP CER CHP 100.0PF 50V
5%
C247 2113944A40 CAP CER CHP 100.0PF 50V
5%
C248 2113946K02 CAP CER CHP 0.10UF 16V
C250 2113944A22 CAP CER CHP 7.5PF 50V +/-
0.5PF
C251 2113944A40 CAP CER CHP 100.0PF 50V
5%
C252 2113944A25 CAP CER CHP 10.0PF 50V +/
- 0.5PF
C253 2113944C12 CAP CER CHP 1.8PF 50V +/-
0.25PF
C254 2113944A14 CAP CER CHP 3.6PF 50V +/-
0.25PF
C255 2113944A40 CAP CER CHP 100.0PF 50V
5%
C257 2113944A40 CAP CER CHP 100.0PF 50V
5%
C258 2113945B02 CAP CER CHP 10,000PF 25V
10%
C259 2113945B02 CAP CER CHP 10,000PF 25V
10%
C260 2113944A40 CAP CER CHP 100.0PF 50V
5%
C263 2113944A62 CAP,FXD,.75PF,.25PF+/-
,50V-DC,040
C264 2113944A40 CAP CER CHP 100.0PF 50V
5%
C265 NOTPLACED -
C271 NOTPLACED -
C272 NOTPLACED -
C273 2113946K02 CAP CER CHP 0.10UF 16V
C276 2113946N03 CAP CER CHP 2.2UF 16V
C277 2113944A40 CAP CER CHP 100.0PF 50V
5%
C278 2313960D07 CAP TANT 10 UF 10% 16V
3528-21
C279 2113946N03 CAP CER CHP 2.2UF 16V
C281 2113944A40 CAP CER CHP 100.0PF 50V
5%
C285 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
