Motorola GP series - Page 231

UHF PCB 8415234H01 (EPP) Parts List 3-87
C466 2113944A40 CAP CER CHP 100.0PF 50V
5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113944A40 CAP CER CHP 100.0PF 50V
5%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C475 2113743H14 CAP CHIP 10.0 UF 16V +80-
20%
C476 2113946R01 CAP CER CHP 10.0UF 10V
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 2113946B04 CAP CER CHP 0.10UF 10V
10%
C490 2113944A40 CAP CER CHP 100.0PF 50V
5%
C491 2113944A40 CAP CER CHP 100.0PF 50V
5%
C492 2113944A40 CAP CER CHP 100.0PF 50V
5%
C493 2113944A40 CAP CER CHP 100.0PF 50V
5%
C494 2113944A40 CAP CER CHP 100.0PF 50V
5%
C495 2113944A40 CAP CER CHP 100.0PF 50V
5%
C496 2113944A40 CAP CER CHP 100.0PF 50V
5%
C497 2113944A40 CAP CER CHP 100.0PF 50V
5%
C498 NOTPLACED -
C499 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C503 2113944A40 CAP CER CHP 100.0PF 50V
5%
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2113944A40 CAP CER CHP 100.0PF 50V
5%
C525 2113944A40 CAP CER CHP 100.0PF 50V
5%
C526 2113944A40 CAP CER CHP 100.0PF 50V
5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 2113944A40 CAP CER CHP 100.0PF 50V
5%
C610 2113944A40 CAP CER CHP 100.0PF 50V
5%
C611 2113944A40 CAP CER CHP 100.0PF 50V
5%
C612 2113944A40 CAP CER CHP 100.0PF 50V
5%
C613 2113944A40 CAP CER CHP 100.0PF 50V
5%
C615 2113944A40 CAP CER CHP 100.0PF 50V
5%
C616 2113944A40 CAP CER CHP 100.0PF 50V
5%
C618 2113944A40 CAP CER CHP 100.0PF 50V
5%
C619 2113944A40 CAP CER CHP 100.0PF 50V
5%
C620 2113944A40 CAP CER CHP 100.0PF 50V
5%
C621 2113944A40 CAP CER CHP 100.0PF 50V
5%
C622 2113944A40 CAP CER CHP 100.0PF 50V
5%
CR101 4880973Z02 Pin Diode
CR102 4815257H01 Surface Mount Pin Diodes
CR103 4815257H01 Surface Mount Pin Diodes
CR105 5115022H01 IC,TEMP
SENS,LM50C,SM,SOT-23
CR160 NOTPLACED -
CR201 4815011H01 DIODE,SWG,300MA,80V
Circuit
Ref
Motorola
Part No.
Description
CR203 4815072H01 DIODE,VCTR,1SV232,30V
CR241 4815071H01 DIODE,VCTR,1SV228,15V
CR242 4815279H01 BBY5503WE6327 From Infin-
eon
CR243 4815279H01 BBY5503WE6327 From Infin-
eon
CR251 4815322H01 VHF Variable Capacitance
Diode
CR301 4815279H01 BBY5503WE6327 From Infin-
eon
CR302 4815279H01 BBY5503WE6327 From Infin-
eon
CR303 4815048H01 Diode,SHTK,MMBD353LT1,S
M,7V
CR304 4815279H01 BBY5503WE6327 From Infin-
eon
CR305 4815279H01 BBY5503WE6327 From Infin-
eon
CR306 4802245J42 Ring Quad Diode SOT-143
PKG
CR311 4813974A19 Diode Schottky Barrier Series
CR312 4815047H01 Diode,SWG,DAN235EFTL,35
V
CR313 4815047H01 Diode,SWG,DAN235EFTL,35
V
CR411 4815067H01 Diode
Array,SWG,RB731UFT108,S
MD,1M
CR412 4815067H01 Diode
Array,SWG,RB731UFT108,S
MD,1M
CR413 4815067H01 Diode
Array,SWG,RB731UFT108,S
MD,1M
CR440 4813978C02 PB Free, Not Completely
Enriched
CR501 4815155H01 Rectifier
CR503 4805729G49 Diode Red/Yel
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E101 2484657R01 Inductor Bead Chip
E400 2480640Z01 Surface Mount Ferrite Bead
E401 2480640Z01 Surface Mount Ferrite Bead
E402 2480640Z01 Surface Mount Ferrite Bead
E403 2480640Z01 Surface Mount Ferrite Bead
E404 2480640Z01 Surface Mount Ferrite Bead
E405 2480640Z01 Surface Mount Ferrite Bead
Circuit
Ref
Motorola
Part No.
Description
E406 2480640Z01 Surface Mount Ferrite Bead
E407 2480640Z01 Surface Mount Ferrite Bead
E408 2480640Z01 Surface Mount Ferrite Bead
E409 2480640Z01 Surface Mount Ferrite Bead
E634 2480640Z01 Surface Mount Ferrite Bead
E637 2480640Z01 Surface Mount Ferrite Bead
E638 2480640Z01 Surface Mount Ferrite Bead
E639 2480640Z01 Surface Mount Ferrite Bead
E640 2480640Z01 Surface Mount Ferrite Bead
E641 2480640Z01 Surface Mount Ferrite Bead
E642 2480640Z01 Surface Mount Ferrite Bead
E643 2480640Z01 Surface Mount Ferrite Bead
E644 2480640Z01 Surface Mount Ferrite Bead
E645 2480640Z01 Surface Mount Ferrite Bead
F501 6515076H01 Fuse,FST BLW,3A,24V,Fuse
Chip SMT T
FL201 4805875Z04 CRYSTAL 16.8 MHZ
FL301 9180022M11 XTAL FILTER 44.85MHZ
FL302 9180468V05 SMD455KHZ 4 ELEMENT
CER FLTR
FL303 9115811H03 SMD455KHZ 6 ELEMENT
FL304 9115811H01 SMD455KHZ 6 ELEMENT
FL401 4870368G02 Reflowable Clock OSC XTAL
H101 2680499Z02 Heat Spreader
J101 0985613Z01 Jack,RF
J102 0280519Z02 Nut, Antenna
J400 0915064H03 Connector, ZIF (40 PINS)
J403 0915064H02 CONN,CONN,F,20CONT,CO
NNECTOR, ZIF
J601 0980521ZO3 CONN, ZIF Vertical, 40PINS
J602 0915064H01 CONN,CONN,F,18CONT,Con
nector, ZIF
L101 2479990B02 Air Wound Coil/Green Color
19.61NH
L102 2479990B02 Air Wound Coil/Green Color
19.61NH
L104 2479990B02 Air Wound Coil/Green Color
19.61NH
L105 2462587N22 CHIP IND 390 NH 10%
L106 2479990A02 Air Wound Coil/Green Color
7.66NH
L107 2479990G01 Air Wound Coil/Green Color
33.47NH
L108 2479990A01 Air Wound Coil/Green Color
4.22NH
L109 2479990B01 Air Wound Coil/Green Color
11.03NH
L112 2462587N45 CHIP IND 22 NH 5%
L113 2415016H01 IDCTR,CHIP,5.6NH,5%,1A,C
ER,SM
L114 2462587N45 CHIP IND 22 NH 5%
Circuit
Ref
Motorola
Part No.
Description
