Motorola GP series

UHF PCB 8415234H05 (EPP) Parts List 3-125
R633 0613952R25 CER CHIP RES 100K OHM
5% 0402
R646 0613952R25 CER CHIP RES 100K OHM
5% 0402
R647 0613952Q84 CER CHIP RES 3000 OHM
5 0402
R648 0613952R25 CER CHIP RES 100K OHM
5% 0402
R649 0613952R17 CER CHIP RES 47K OHM
5% 0402
RT400 0680590Z01 THERMISTOR_33K
S501 4080710Z21 SWITCH, FREQUENCY
S502 1880619Z06 POTENTIOMETER,
VOLUME
SH100 2680507Z02 SHIELD, HARMONIC
FILTER
SH101 2680510Z02 SHIELD, PA
SH201 2680511Z02 SHIELD, SYNTHESIZER
SH202 2680511Z02 SHIELD, SYNTHESIZER
SH241 2604120G02 AOBA VCO SHIELD
SH242 2680514Z02 SHIELD, VCO BOTTOM/
LVZIF
SH301 2686583Z02 SHIELD, RECEIVER
FRONT END TOP
SH302 2680555Z02 SHIELD, RECEIVER F/END
BOTTOM
SH303 2680509Z02 SHIELD, MIXER
SH304 2680624Z02 SHIELD, MIXER DIODE
SH322 2686528Z02 SHIELD, IF SECTION
SH323 2686527Z02 SHIELD, RFI/EMI, CRS,
TIN
SH400 2680505Z02 SHIELD, CONTROLLER
TOP LEFT
SH401 2680506Z02 SHIELD, CONTROLLER
TOP RIGHT
Circuit
Ref
Motorola
Part No.
Description
SH402 2680515Z02 SHIELD, CONTROLLER
BOTTOM LEFT
SH403 2680516Z02 SHIELD, CONTROLLER
BTM RIGHT
T301 2515121H01 BALUN, TRANSFORMER
W18 COMP
T302 2515121H01 BALUN, TRANSFORMER
W18 COMP
U101 5115678H01 VHF/UHF/800/900 MHZ
LDMOS DRIV
U102 5185765B26 IC PWR CTRL IN MOS20
U201 5185177Y01 IC TESTED AT25016 48
PIN W18
U210 5115266H01 INVERTER TC7ST04FU
SS0P5-P-A
U211 5115266H01 INVERTER TC7ST04FU
SS0P5-P-A
U241 5105750U56 IC PKG DIE VCO BUFFER
U247 5115026H01 MAX SUPPLY VOL 16V
U248 5115019H01 3.3V REGULATOR IN
SOT23-5 PKG
U301 5115281H01 FM IF IC SA616 FROM
PHILIPS
U302 5115070H01 IC 3-INV LMOS TC7W04FU
U303 NOTPLACE
D
GCAM DUMMY PART
NUMBER
U400 5115012H01 MAX SUPPLY VOL 30V
U404 5115062H01 IC ASFIC_CMP
U405 NOTPLACE
D
GCAM DUMMY PART
NUMBER
U406 5115250H02 NEED CGISS
DESCRIPTION IN ICCS
U407 5115033H01 16K X 8 SPI SERIAL ROM
U409 5185143E03 HC11FL0 (3V) ASIC
MICRO-P
Circuit
Ref
Motorola
Part No.
Description
U410 5115044H01 REGULATOR
3.3V,ILC7062CM-33
U420 5115280H01 AUDIO AMPLIFIER
TDA8547TS
U602 5115014H01 CMOS,MAX SUPPLY VOL
15.5V
VR432 4813979P10 DIODE
ARRAY,TRANSIENT
PROTECTI
VR433 4813979P10 DIODE
ARRAY,TRANSIENT
PROTECTI
VR434 4815038H01 ZENER DIODE-6.8V
VR439 4813977M21 DIODE,ZEN,MBZ5242,SM,
SOT-23,12
VR440 4815038H01 ZENER DIODE-6.8V
VR441 4815038H01 ZENER DIODE-6.8V
VR442 4815038H01 ZENER DIODE-6.8V
VR443 4815038H01 ZENER DIODE-6.8V
VR444 4815038H01 ZENER DIODE-6.8V
VR445 4813977A54 DIODE,ZEN,MM3Z10V,SM,
SOD-323,1
VR446 4813977A54 DIODE,ZEN,MM3Z10V,SM,
SOD-323,1
VR447 4813977A54 DIODE,ZEN,MM3Z10V,SM,
SOD-323,1
VR448 4813977A54 DIODE,ZEN,MM3Z10V,SM,
SOD-323,1
VR449 4813977A54 DIODE,ZEN,MM3Z10V,SM,
SOD-323,1
VR450 4815040H01 ZENER DIODE-12V
VR460 4815038H01 ZENER DIODE-6.8V
VR501 4813977M14 DIODE,ZEN,MBZ5235,SM,
SOT-23,6.
VR506 4815038H01 ZENER DIODE-6.8V
Circuit
Ref
Motorola
Part No.
Description
Y300 4802245J84 XTAL 44.395MHZ, 3RD OT,
SMD
Y301 9186145B02 CER.DISCR.
CDBCA455CX36-TC
