UHF PCB 8415234H08 Schematics 3-135
UHF (403-470 MHz) Harmonic Filter Schematic Diagram
HF SHIELD
C108
390nH
100pF
1
L105
ANT_BIAS
SH100
SHIELD
CR101
L102
17.02nH
16.28nH
L101
TX_OUT
RF_JACK
3.3pF
C107
4.7pF
C106C104
7.5pF
C103
13pF
C102
8.2pF
C101
100pF
L104
19.61nH
20pF
C175
R170
240
R101
2
3
1
CR102
RX_IN
240
