3-156 UHF PCB 8486743Z02 Parts List
C259 2113945B02
CAP CER CHP 10,000PF 25V
10%
C260 2113944A40
CAP CER CHP 100.0PF 50V
5%
C263 2113944A62
CAP,FXD,.75PF,.25PF+/-
,50V-D
C264 2113944A40
CAP CER CHP 100.0PF 50V
5%
C271 NOTPLACED -
C272 NOTPLACED -
C273 2113946K02 CAP CER CHP 0.10UF 16V
C276 2113946N03 CAP CER CHP 2.2UF 16V
C277 2113944A40
CAP CER CHP 100.0PF 50V
5%
C278 2313960D07
CAP TANT 10 UF 10% 16V
3528-21
C279 2113946N03 CAP CER CHP 2.2UF 16V
C281 2113944A40
CAP CER CHP 100.0PF 50V
5%
C285 2113944A40
CAP CER CHP 100.0PF 50V
5%
C286 2113946K02 CAP CER CHP 0.10UF 16V
C289 2113944A40
CAP CER CHP 100.0PF 50V
5%
C291 2313960M51
CAP TANT 10 UF 10% 6.3V
2012-1
C292 2113946K02 CAP CER CHP 0.10UF 16V
C293 2113945G98
CAP,FXD,.47UF,+10%,-
10%,50V-D
C294 2113944A40
CAP CER CHP 100.0PF 50V
5%
C295 2113944A40
CAP CER CHP 100.0PF 50V
5%
C296 2113946K02 CAP CER CHP 0.10UF 16V
C297 2113945B02
CAP CER CHP 10,000PF 25V
10%
C298 2113946K02 CAP CER CHP 0.10UF 16V
C301 2113944A14
CAP CER CHP 3.6PF 50V +/-
0.25
C302 2113944A25
CAP CER CHP 10.0PF 50V +/
- 0.5
C303 2113944M08
CAP,FXD,3.9PF,.1PF+/-,50V-
DC
C304 2113944A25
CAP CER CHP 10.0PF 50V +/
- 0.5
C305 2113944A80
CAP,FXD,20PF,+5%,-
5%,50V-DC,0
Circuit
Ref
Motorola
Part No.
Description
C306 NOTPLACED -
C307 2113944A40
CAP CER CHP 100.0PF 50V
5%
C308 2113944A40
CAP CER CHP 100.0PF 50V
5%
C309 2113944A40
CAP CER CHP 100.0PF 50V
5%
C310 2113944A40
CAP CER CHP 100.0PF 50V
5%
C311 NOTPLACED -
C312 2113944A24
CAP CER CHP 9.1PF 50V +/-
0.5P
C313 2113944A25
CAP CER CHP 10.0PF 50V +/
- 0.5
C314 2113946K02 CAP CER CHP 0.10UF 16V
C315 2113944A40
CAP CER CHP 100.0PF 50V
5%
C316 2113944M08
CAP,FXD,3.9PF,.1PF+/-,50V-
DC
C317 2113944A24
CAP CER CHP 9.1PF 50V +/-
0.5P
C318 2113944A22
CAP CER CHP 7.5PF 50V +/-
0.5P
C319 2113944A11
CAP CER CHP 2.7PF 50V +/-
0.25
C320 2113944A79
CAP,FXD,16PF,+5%,-
5%,50V-DC,0
C321 2113944A40
CAP CER CHP 100.0PF 50V
5%
C322 2113944A38
CAP CER CHP 82.0PF 50V
5%
C324 2113944A29
CAP CER CHP 22.0PF 50V
5%
C325 2115153H26 CAP, CERAMIC, COG
C326 2113946K02 CAP CER CHP 0.10UF 16V
C327 2113946K02 CAP CER CHP 0.10UF 16V
C334 2113945A13
CAP CER CHP 4700PF 50V
10%
C338 NOTPLACED -
C343 2113946K02 CAP CER CHP 0.10UF 16V
C344 2113945C31
CAP,FXD,.1UF,+10%,-
10%,50V-DC
C345 2113946K02 CAP CER CHP 0.10UF 16V
C346 2113946K02 CAP CER CHP 0.10UF 16V
C347 2113946K02 CAP CER CHP 0.10UF 16V
C348 2113946K02 CAP CER CHP 0.10UF 16V
Circuit
Ref
Motorola
Part No.
Description
C349 2113945C31
CAP,FXD,.1UF,+10%,-
10%,50V-DC
C350 2113946K02 CAP CER CHP 0.10UF 16V
C351 2113944A41
CAP CER CHP 120.0PF 50V
5%
C355 2113946K02 CAP CER CHP 0.10UF 16V
C357 2113946K02 CAP CER CHP 0.10UF 16V
C360 2113944A25
CAP CER CHP 10.0PF 50V +/
- 0.5
C361 2113946K02 CAP CER CHP 0.10UF 16V
C364 2113944A81
CAP,FXD,24PF,+5%,-
5%,50V-DC,0
C366 NOTPLACED -
C367 2113944A82
CAP,FXD,30PF,+5%,-
5%,50V-DC,0
C370 2113944A17
CAP CER CHP 4.7PF 50V +/-
0.25
C371 NOTPLACED -
C372 2113944A40
CAP CER CHP 100.0PF 50V
5%
C373 NOTPLACED -
C374 2113944A40
CAP CER CHP 100.0PF 50V
5%
C378 0613952J01
CER CHIP RES 10K OHM 5%
0603
C380 2113945B02
CAP CER CHP 10,000PF 25V
10%
C381 NOTPLACED -
C382 2313960B57
CAP,TANTALUM,10UF,+10%
,-10%,4V
C383 2113944A40
CAP CER CHP 100.0PF 50V
5%
C385 2113944A82
CAP,FXD,30PF,+5%,-
5%,50V-DC,0
C386 2113944A40
CAP CER CHP 100.0PF 50V
5%
C400 2113945B02
CAP CER CHP 10,000PF 25V
10%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C402 2113946K02 CAP CER CHP 0.10UF 16V
C403 2113955D33
CAP,FXD,2.2UF,+10%,-
10%,16V-D
C405 2113946K02 CAP CER CHP 0.10UF 16V
C408 2113944A40
CAP CER CHP 100.0PF 50V
5%
C409 2113946K02 CAP CER CHP 0.10UF 16V
C410 2113946L03 CAP CER CHP 0.22UF 16V
Circuit
Ref
Motorola
Part No.
Description
C412 2113946B04
CAP CER CHP 0.10UF 10V
10%
C414 2113946K02 CAP CER CHP 0.10UF 16V
C415 2185895Z01
CAPACITOR CER LOW DIST
.01UF
C416 2113946B04
CAP CER CHP 0.10UF 10V
10%
C418 2113946B04
CAP CER CHP 0.10UF 10V
10%
C419 NOTPLACED -
C420 2113945B02
CAP CER CHP 10,000PF 25V
10%
C421 2113946B04
CAP CER CHP 0.10UF 10V
10%
C422 2113946K02 CAP CER CHP 0.10UF 16V
C423 2113944A40
CAP CER CHP 100.0PF 50V
5%
C424 NOTPLACED -
C425 2113946K02 CAP CER CHP 0.10UF 16V
C426 2113944A40
CAP CER CHP 100.0PF 50V
5%
C427 2113944A40
CAP CER CHP 100.0PF 50V
5%
C428 2113946K02 CAP CER CHP 0.10UF 16V
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946B04
CAP CER CHP 0.10UF 10V
10%
C431 2113944A40
CAP CER CHP 100.0PF 50V
5%
C433 2113945B02
CAP CER CHP 10,000PF 25V
10%
C435 2113946K02 CAP CER CHP 0.10UF 16V
C437 2113946L03 CAP CER CHP 0.22UF 16V
C440 2113946Q01 CAP CER CHP 4.7UF 16V
C441 2113944A40
CAP CER CHP 100.0PF 50V
5%
C442 2113945C31
CAP,FXD,.1UF,+10%,-
10%,50V-DC
C443 2113945C31
CAP,FXD,.1UF,+10%,-
10%,50V-DC
C444 2113944A40
CAP CER CHP 100.0PF 50V
5%
C445 2113945C31
CAP,FXD,.1UF,+10%,-
10%,50V-DC
C447 2113945B04
CAP,FXD,.022UF,+10%,-
10%,25V-
Circuit
Ref
Motorola
Part No.
Description
