Motorola GP series - Page 303

UHF PCB 8486743Z02 Parts List 3-159
R131 NOTPLACED -
R132 0613952R35
CER CHIP RES 270K OHM
5% 0402
R133 0613952J01
CER CHIP RES 10K OHM 5%
0603
R134 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R135 0613952R17
CER CHIP RES 47K OHM 5%
0402
R137 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R138 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R139 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R140 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R142 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R144 0613952H72
CER CHIP RES 910 OHM 5%
0603
R145 0613952H72
CER CHIP RES 910 OHM 5%
0603
R146 NOTPLACED -
R147 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R161 0613952Q64
CER CHIP RES 430 OHM 5%
0402
R162 0613952Q64
CER CHIP RES 430 OHM 5%
0402
R170 0613952H58
CER CHIP RES 240 OHM 5%
0603
R172 0613952H48
CER CHIP RES 91.0 OHM
5% 0603
R173 0613952H48
CER CHIP RES 91.0 OHM
5% 0603
R174 0613952R09
CER CHIP RES 22K OHM 5%
0402
R175 0613952H12
CER CHIP RES 3.0 OHM 5%
0603
R176 0613952H12
CER CHIP RES 3.0 OHM 5%
0603
R179 0616124H19
THIN FILM MELF RES-56
OHM
R188 NOTPLACED -
R201 0613952R23
CER CHIP RES 82K OHM 5%
0402
Circuit
Ref
Motorola
Part No.
Description
R202 0613952R25
CER CHIP RES 100K OHM
5% 0402
R204 0613952R17
CER CHIP RES 47K OHM 5%
0402
R231 0613952Q51
CER CHIP RES 120 OHM 5%
0402
R232 0613952Q68
CER CHIP RES 620 OHM 5%
0402
R233 0613952Q67
CER CHIP RES 560 OHM 5%
0402
R241 0613952Q31
CER CHIP RES 18.0 OHM
5% 0402
R242 0613952Q56
CER CHIP RES 200 OHM 5%
0402
R243 0613952R01
CER CHIP RES 10K OHM 5%
0402
R244 0613952R03
CER CHIP RES 12K OHM 5%
0402
R245 0613952Q58
CER CHIP RES 240 OHM 5%
0402
R248 0613952Q36
CER CHIP RES 30.0 OHM
5% 0402
R251 0613952Q31
CER CHIP RES 18.0 OHM
5% 0402
R252 0613952Q61
CER CHIP RES 330 OHM 5%
0402
R253 0613952Q94
CER CHIP RES 7500 OHM
5% 0402
R254 0613952Q94
CER CHIP RES 7500 OHM
5% 0402
R255 0613952Q88
CER CHIP RES 4300 OHM
5% 0402
R256 0613952Q36
CER CHIP RES 30.0 OHM
5% 0402
R260 0613952Q73
CER CHIP RES 1000 OHM
5% 0402
R281 NOTPLACED
R282 0613952D15
CER CHIP RES 1400 OHM
1% 0603
R283 0613952D15
CER CHIP RES 1400 OHM
1% 0603
R285 0613952D15
CER CHIP RES 1400 OHM
1% 0603
R286 0613952D15
CER CHIP RES 1400 OHM
1% 0603
R287 0613952D15
CER CHIP RES 1400 OHM
1% 0603
Circuit
Ref
Motorola
Part No.
Description
R288 NOTPLACED
R291 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R292 0613952D05
CER CHIP RES 1100 OHM
1% 0603
R301 0613952J25
CER CHIP RES 100K OHM
5% 0603
R302 0613952R25
CER CHIP RES 100K OHM
5% 0402
R303 0613952Q80
CER CHIP RES 2000 OHM
5% 0402
R304 0613952R03
CER CHIP RES 12K OHM 5%
0402
R305 0613952Q66
CER CHIP RES 510 OHM 5%
0402
R306 0613952R25
CER CHIP RES 100K OHM
5% 0402
R307 0613952R25
CER CHIP RES 100K OHM
5% 0402
R308 0613952Q42
CER CHIP RES 51.0 OHM
5% 0402
R309 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R310 NOTPLACED -
R311 0613952R13
CER CHIP RES 33K OHM 5%
0402
R312 0613952Q89
CER CHIP RES 4700 OHM
5% 0402
R313 0613952Q61
CER CHIP RES 330 OHM 5%
0402
R314 0613952Q78
CER CHIP RES 1600 OHM
5% 0402
R315 0613952R03
CER CHIP RES 12K OHM 5%
0402
R320 NOTPLACED -
R321 0613952Q82
CER CHIP RES 2400 OHM
5% 0402
R322 0613952Q73
CER CHIP RES 1000 OHM
5% 0402
R328 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R330 0613952R01
CER CHIP RES 10K OHM 5%
0402
R331 0613952Q56
CER CHIP RES 200 OHM 5%
0402
R332 0613952R03
CER CHIP RES 12K OHM 5%
0402
Circuit
Ref
Motorola
Part No.
Description
R333 NOTPLACED -
R339 0613952Q88
CER CHIP RES 4300 OHM
5% 0402
R340 0613952Q94
CER CHIP RES 7500 OHM
5% 0402
R342 0613952R25
CER CHIP RES 100K OHM
5% 0402
R344 0613952Q42
CER CHIP RES 51.0 OHM
5% 0402
R346 0613952R05
CER CHIP RES 15K OHM 5%
0402
R348 0613952Q86
CER CHIP RES 3600 OHM
5% 0402
R349 2113945L25
CAP,FXD,1000PF,+5%,-
5%,50V-DC
R350 0613952Q85
CER CHIP RES 3300 OHM
5% 0402
R359 NOTPLACED -
R363 0613952Q63
CER CHIP RES 390 OHM 5%
0402
R364 0613952Q79
CER CHIP RES 1800 OHM
5% 0402
R365 0613952Q75
CER CHIP RES 1200 OHM
5% 0402
R366 0613952R03
CER CHIP RES 12K OHM 5%
0402
R367 0613952Z55
RES,MF,12KOHM,1%,.0625
W,SM,040
R368 0613952N01
CER CHIP RES 10.0K OHM
1% 0402
R369 0613952Q69
CER CHIP RES 680 OHM 5%
0402
R400 0613952R17
CER CHIP RES 47K OHM 5%
0402
R405 0613952Q66
CER CHIP RES 510 OHM 5%
0402
R406 0613952R22
CER CHIP RES 75K OHM 5%
0402
R408 NOTPLACED -
R409 0613952R01
CER CHIP RES 10K OHM 5%
0402
R410 0613952R25
CER CHIP RES 100K OHM
5% 0402
R411 0613952R01
CER CHIP RES 10K OHM 5%
0402
R412 0613952Q89
CER CHIP RES 4700 OHM
5% 0402
Circuit
Ref
Motorola
Part No.
Description
