Motorola GP series

UHF2 PCB8485641Z02 / PCB8485677Z02 Parts List 3-15
PB503 4080523Z01 TACTILE PUSH BUTTON
PB504 4080523Z01 TACTILE PUSH BUTTON
PB505 4080523Z01 TACTILE PUSH BUTTON
Q110 4802245J55 RF POWER FET
Q111 4802245J50 DUAL NPN/PNP
Q210 4802245J50 DUAL NPN/PNP
Q241 4805218N63 NPN
Q260 4802245J50 DUAL NPN/PNP
Q261 4802245J50 DUAL NPN/PNP
Q301 4802245J44 NPN
Q302 4802245J44 NPN
Q315 4880214G02 NPN
Q320 4805218N63 NPN
Q400 4809579E18 MOSFET P-CHAN
Q403 4880214G02 NPN
Q405 4802245J54 DUAL NPN
Q410 4802245J54 DUAL NPN
Q411 4802245J54 DUAL NPN
Q416 4809579E18 MOSFET P-CHAN
Q417 4802245J50 DUAL NPN/PNP
Q502 5180159R01 DUAL NPN
Q505 4880214G02 NPN
R101 0662057A34 240
R102 0680735Z01 0.075
R104 0662057N15 47K
R106 0662057M26 10
R108 0662057M92 5.6K
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43K
R130 0662057M98 10K
R131 0662057N05 18K
R132 0662057N33 270K
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43K
R172 0662057A32 200
R173 0662057N29 180K
R191 0662057C01 0 ohm
R201 0662057N21 82K
R202 0662057N23 100K
R204 0662057N15 47K
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M52 120
R243 0662057M98 10K
R244 0662057N03 15K
Circuit
Ref.
Motorola
Part No.
Description
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M38 33
R252 0662057M60 270
R253 0662057M95 7.5K
R254 0662057M96 8.2K
R255 0662057M89 4.3K
R256 0662057M37 30
R260 0662057M74 1K
R300 0662057M82 2.2K
R301 0662057N23 100K
R302 0662057N23 100K
R303 0662057M78 1.5K
R304 0662057N01 12K
R305 0662057M66 470
R306 0662057N23 100K
R307 0662057N23 100K
R308 0662057M60 270
R309 0662057M32 18
R310 0662057M60 270
R311 0662057N10 30K
R312 0662057M83 2.4K
R313 0662057M62 330
R314 0662057M85 3K
R315 0662057N01 12K
R316 0662057A96 91K
R317 0662057M74 1K
R318 0662057A79 18K
R319 0662057A29 150
R320 0662057M74 1K
R321 0662057M83 2.4K
R322 0662057N30 200K
R324 0662057M81 2K
R325 0662057M94 6.8K
R327 0662057N11 33K
R328 0662057M12 2.7
R329 0662057M01 0
R339 0662057M01 0
R340 0662057M96 8.2K
R342 0662057N23 100K
R343 0662057M26 10
R344 0662057N01 12K
R345 0662057M98 10K
R346 0662057N17 56K
R347 0662057M74 1K
R348 0662057M87 3.6K
R349 0662057C01 0
R350 0662057N23 100K
R351 0662057C01 0
R352 0662057M86 3.3K
R355 0662057M01 0
Circuit
Ref.
Motorola
Part No.
Description
R400 0662057N15 47K
R401 0662057M01 0
R405 0662057M01 0
R406 0662057N20 75K
R407 0662057N19 68K
R409 0662057M98 10K
R410 0662057N23 100K
R411 0662057M98 10K
R413 0662057M01 0
R414 0662057V34 180K
R415 0662057V26 91K
R416 0662057N13 39K
R418 0662057M01 0
R419 0662057M67 0
not used in GP640
R420 0662057B46 10.0 MEG
not used in GP640
R421 0662057M81 2K
R423 0662057N39 470K
R424 0662057N12 36K
R425 0662057N10 30K
R426 0662057N35 330K
not used in GP640
R427 0662057M84 2.7K
R428 0662057M10 2.2
R429 0662057M98 10K
R431 0662057N39 470K
R432 0662057N16 51K
R434 0662057M62 330
R435 0662057M81 2K
R436 0662057M01 0
R445 0662057N08 24K
R446 0662057N31 220K
R447 0662057N51 1.5MEG
R448 0662057N33 270K
R449 0662057N08 24K
R450 0683962T45 68
R457 0662057M98 10K
R460 0662057M90 4.7K
R461 0662057M56 180
not used in GP640
R462 0662057M98 10K
not used in GP640
R463 0662057M61 300
R471 0662057M92 5.6K
R472 0662057N12 36K
R473 0662057M26 10
R475 0662057M01 0
R476 0662057N08 24K
R477 0662057M74 1K
R478 0662057M98 10K
Circuit
Ref.
Motorola
Part No.
Description
R481 0662057N08 24K
R492 0662057M01 0
R501 0662057M70 680
R502 0662057M56 180
R505 0662057M98 10K
R506 0662057N15 47K
R507 0662057M01 0
R701 0662057N05 18K
used in GP1280 only
R702 0662057N05 18K
used in GP1280 only
R703 0662057M74 1K
used in GP1280 only
R704 0662057N13 39K
used in GP1280 only
R705 0662057N13 39K
used in GP1280 only
R706 0662057N17 56K
used in GP1280 only
R707 0662057M91 5.1K
used in GP1280 only
R708 0662057N41 560K
used in GP1280 only
R709 0662057N47 1.0 MEG
used in GP1280 only
R710 0662057N39 470K
used in GP1280 only
R716 0662057N01 12K
used in GP1280 only
R717 0662057M82 2.2K
used in GP1280 only
RT300 0680590Z01 THERMISTOR_33K
RT400 0680590Z01 THERMISTOR_33K
S501 4080710Z01 CHANNEL SWITCH
used in GP640 only
4080710Z02 CHANNEL SWITCH
not used in GP640
S502 1880619Z01 VOLUME SWITCH
SH100 2680507Z01 SHIELD, HARMONIC FILTER
SH101 2680510Z01 SHIELD, PA
SH201 2680511Z01 SYNTHESIZER TOP SHIELD
SH202 2680511Z01 SYNTHESIZER BOTTOM
SHIELD
SH241 2680513Z01 SHIELD, VCO TOP
SH242 2680514Z01 SHIELD, VCO BOTTOM/
LVZIF
SH301 2680554Z01 RX PRE FILTER SHIELD
SH302 2680555Z01 RX POST FILTER/RX AMP
SH303 2680509Z01 SHIELD, MIXER
SH304 2680624Z01 SHIELD, MIXER DIODE
SH321 2680508Z01 SHIELD,LVZIF 2ND LO
Circuit
Ref.
Motorola
Part No.
Description
